Removing temperature sensor for right side
Installation Location
1 - Temperature sensor, right side
2 - Temperature sensor, left side
Scheme 325
1. Turn the temperature sensor to the inside of the vehicle -arrow A- and remove it from the air duct -arrow B-. (Scheme 325)
2. Release the plug -arrows C- and pull off -arrow D-. (Scheme 325)
Scheme 326
1. Check sealing ring for signs of damage -a- and replace if necessary. (Scheme 326)
2. Insert the plug -arrow A- until the locking tabs -arrows B- are felt to engage. (Scheme 326)
3. Insert temperature sensor -arrow C- and turn it to the inside of the vehicle -arrow D- until the locking tabs -b- engage. (Scheme 326)
Scheme 327
4. Fold back the carpeted floor -arrow- and align it. (Scheme 327)
Scheme 328
1. Check sealing ring -a- for signs of damage and replace if necessary. (Scheme 328)
2. Insert the plug -arrow A- until the locking tabs -arrows B- are felt to engage. (Scheme 328)
3. Insert temperature sensor -arrow C- and turn it to the inside of the vehicle -arrow D- until the locking tabs -b- engage. (Scheme 328)
1. Install rear side trim panel. Refer to 70 03 19 Removing and installing rear luggage compartment side-trim panel - as of MY 2003 (All Models).
2. Install left rear backrest. Refer to 72 47 19 Removing and installing rear backrest - as of MY 2003 (All Models).
3. Install trim panel for left luggage compartment floor with tie-down ring. Refer to 70 06 19 Removing and installing luggage compartment trim (loadspace cover) - as of MY 2003 (All Models).
4. Install C-pillar trim panel Refer to 70 68 19 Removing and installing C-pillar trim panel - as of MY 2003 (All Models).
5. Install D-pillar trim panel. Refer to 70 69 19 Removing and installing D-pillar trim - as of MY 2003 (All Models).
6. Install rear roof trim panel. Refer to 70 85 19 Removing and installing rear roof lining - as of MY 2003 (All Models).
1. Remove rear side trim panel. Refer to 70 03 19 Removing and installing rear luggage compartment side-trim panel - as of MY 2003 (All Models).
2. Remove additional air conditioner. > 881019 Removing and installing additional air conditioner - chapter on "removing"
3. Remove expansion valve. > 887019 Removing and installing expansion valve for additional air conditioner - chapter on "removing"
