Removing selector frame Porsche Cayenne I рестайлинг

Automatic - Actuation, Assembly Housing 8 illustrations ~169 words

Removing selector frame

Installation Location

Scheme 23

Scheme 23: Removing selector frame
Scheme 23: Removing selector frame

Scheme 24

Scheme 24
Scheme 24

1. Remove cover of center console. To do this unscrew two screws -right arrows-, separate plug connection -inset-, tip cover up -curved arrow- and back and remove. (Scheme 23)

Scheme 25

Scheme 25
Scheme 25

2. Remove selector lever cover with special tool unlocking hook P 9713. To do this hook into the left and right of the unlocking bracket -inset- from the front and press outwards. Pull the cover upwards slightly at the same time. (Scheme 24)

3. Unlock the rear unlocking brackets in the same way.

Scheme 26

Scheme 26
Scheme 26

4. Remove selector lever cover and separate cable connection.

Scheme 27

Scheme 27
Scheme 27

5. Pull off electrical plug connections.

Scheme 28

Scheme 28
Scheme 28

6. Remove the transverse strut of the center console.

Scheme 29

Scheme 29
Scheme 29

7. Unscrew selector frame screws -arrows-. (Scheme 28)

Scheme 30

Scheme 30
Scheme 30

8. Unscrew cable fastening screw -right arrow- on the cable adjustment using special tool special inserts model AB NR.170 and remove retaining clip -left arrow-. (Scheme 29)

9. Remove selector frame.
