Subsequent work
1. Install headliner. Refer to 70 84 19 Removing and installing roof lining - as of MY 2003 (All Models) .
Installation Location
Scheme 58
Remove the ignition key and switch off the radio.
1. Open the glasses compartment and undo both fastening screws.
2. Detach roof console around sliding roof switch and allow it to hang down to the front.
Note. The number of plug connections can vary, depending on the vehicle equipment. Disconnect all plug connections for removing the roof console.
3. Press electrical plug on the compartment sensor and unplug.
Scheme 59
4. Press the electric connector on the printed circuit board and unplug.
5. Detach the roof console from the mounts on the roof liner at the left and right.
Scheme 60
6. Unscrew the three fastening screws from the motor.
7. Press the electric connector together -a- and disconnect. (Scheme 59)
Installation Location
Scheme 61
1. Press in the electric plug until it clicks into place.
2. Position motor and secure with the fastening screws. Tightening torque 2.5 ftlb.
3. Attach the roof console to the mounts on the roof liner at the left and right and plug in all electrical connections.
Scheme 62
4. Push the electrical plug for the circuit board until it clicks into place.
5. Fold up roof console, clip it in the roof liner and screw down using the two fastening screws. Close glasses compartment.
