Installing closing panel
Installation Location
1. Fit the closing panel to the body.
1.1. Position the closing panel on the body and fix in place with tensioning clamps. Ensure that the closing panel is positioned flat at the connection point for the bumper.
Scheme 623
2. Resistance spot-weld the closing panel.
2.1. Resistance spot-weld the closing panel in areas -A, B- ( -A, B- ) and -C, D-. (Scheme 623), (Scheme 625), (Scheme 624).
Scheme 624
Scheme 625
Scheme 626
3. Inert gas arc weld the closing panel.
3.1. Inset gas arc weld the closing panel in the area -E- ( -E- ) with a full weld. (Scheme 623), (Scheme 625).
