Removing drive plate for torque converter
Note. Shims are fitted under or on the drive plate. These must be refitted again at the same place they were before the drive plate was removed. The shims are to be marked with a felt-tip pen before removal.
1. Block drive plate. For this, block the crankshaft at the belt pulley with the arm bracket Arm bracket T10069.
2. Unscrew drive plate. To do this, loosen the diagonal fastening screws.
3. Remove drive plate.
4. If drive plate is tight, lever off with a screwdriver where necessary.
Installing drive plate for torque converter
Note. Clean the crankshaft flange before installing the drive plate (remove rust). Use a special metal-polishing pad (e. g. Never Dull) for this.
1. Fit drive plate.
2. Block drive plate. For this, block the crankshaft at the belt pulley with the arm bracket Arm bracket T10069.
3. Correctly fit the shims according to the removal marking.
4. Tighten the new fastening screws diagonally. --> Initial tightening: 44 ftlb.
> Torque angle: 90 °
> Torque angle: 30 °
1. Block drive plate. To do this, attach toothed segment 95381 to a screw hole in the crankcase so that at least one tooth is in contact with the starter teeth.
2. Unscrew drive plate. To do this, loosen the ten diagonally opposite fastening screws.
3. Remove drive plate.
4. If the drive plate is stuck, remove it using an internal puller and slide hammer.
Scheme 270
5. To do this, insert internal puller into the middle of the drive plate and tighten.
Scheme 271
6. Then screw on the slide hammer and knock off the drive plate.
Note. Clean the crankshaft stub before installing the drive plate (remove rust). Use a special metal-polishing pad (e. g. Never Dull) for this.
1. Fit drive plate.
2. Block drive plate. To do this, attach toothed segment 95381 to a screw hole in the crankcase so that at least one tooth is in contact with the starter teeth.
3. Tighten the ten new fastening screws crosswise. --> Tightening torque: 44 ftlb. ; then --> Torque angle: 90 °
4. Remove toothed segment 95381.
