Subsequent work Porsche Cayenne I

Subsequent work

1. Insert fuses -3- for the ignition rod modules, -4- injection system and both fuel pump relays (left pump -1- and right pump -2- ). (Scheme 20)

2. Fit lid of central electrics box. To do this, fit the four fastening screws.

3. Fit the design cover.

Scheme 21

A - Fuel transfer unit (This tool has been tested and approved by PORSCHE.); see Workshop Equipment Manual 3.2.2. "WE 1262"

B - Fuel nozzle - special accessory (This can be used to refuel the vehicle. The fuel nozzle switches off automatically as soon as the fuel tank is full.); see Workshop Equipment Manual 3.2.2 "WE 1262"

C - Porsche adapter (This adapter fits 8-mm to 10-mm fuel lines (986; 996 and Cayenne.); see Workshop Equipment Manual 3.2.2 "WE 1262"

D - Connecting piece between Porsche adapter and suction line (This is screwed into suction line E and connected to the Porsche adapter.); see Workshop Equipment Manual 3.2.2 "WE 1262"

E - Suction line with venting device (Always attach venting device (rubber taper with transparent hose) to the filler neck. This minimises the amount of escaping fuel vapours.); see Workshop Equipment Manual 3.2.2. "WE 1262"

ohne Bezeichnung - Adapter adapter P 9479 (For controlling the fuel pumps); see Workshop Equipment Manual, Chapter 2.2.2

Scheme 22

1 - Air connection (connection for unlubricated/oil-free compressed air)

2 - Fuel tank (capacity: 110 litres), (Tank can be changed. The scale at the side starts at approx. 10 litres. Other markings are shown in 5-litre steps.)

3 - Pump reversal (This allows you to change the direction of the pump from the fuel feed direction.)

4 - Operating pressure display (Displays the set operating pressure of the pump. The value cannot be more than 6.5 bar.)

5 - On/Off switch (For switching the pump on and off.)

Scheme 23

1. Connect the fuel hose -1- to the changeover tank. Connect the venting device (transparent hose) to the changeover tank. Then attach the pneumatic stop switch -3- to the tank and tighten the two knurled nuts. (Scheme 22)

2. Connect the suction hose (or fuel nozzle) to the connection -1- and then connect the venting device -2-. (Scheme 22)

Scheme 24

3. When using the pump, always make sure that the earth cable is attached to the relevant vehicle. Use an unpainted metal part (e. g. the catch bar) for this.

Scheme 25

Note. Fuel can be removed directly through the fuel filler neck on older vehicles or vehicles from other manufacturers by removing the connecting piece.
