Removing transfer box control module Porsche Cayenne I

Final Drive, Diferential, Differential Lock 5 illustrations ~177 words

Removing transfer box control module

Installation Location

Scheme 33

Scheme 33: Removing transfer box control module
Scheme 33: Removing transfer box control module

Note. The control unit is located under the right front seat.

1. The ignition key must be removed before removing the connector from the control unit.

2. Move right front seat all the way back and up.

3. For vehicles with a telephone, remove the telephone control unit. Refer to 91 90 19 Removing and installing control unit for telephone - as of MY 2003 (All Models).

4. Unclip right front seat trim and remove drawer.

Scheme 34

Scheme 34
Scheme 34

5. Unscrew the fastening screw for the support.

Scheme 35

Scheme 35
Scheme 35

Note. Only for vehicles with telephone

6. Unscrew the three fastening nuts and remove support for telephone control unit.

7. Move seat all the way forward and remove ignition key.

Scheme 36

Scheme 36
Scheme 36

8. Release the two connectors -A- and pull them off -B-. (Scheme 36)

9. Remove the support with the two control units -C-. (Scheme 36)

Scheme 37

Scheme 37
Scheme 37

10. Press the two locking mechanisms outwards -A- and remove the control unit -B-. (Scheme 37)
