Cooling: Overview Porsche Cayenne I

Component overview

1 - Radiator module (If at all possible, do not open the air-conditioning system. Do not bend the lines.

2 - Lock carrier

3 - Front bumper

4 - 2 clamps

5 - Safety clip

Installation Location

Scheme 8

Scheme 9

1 - Distributor pipe

2 - Coolant temperature sensor (when removing, collect emerging coolant, when installing, replace sealing ring)

3 - Sealing ring (replace when installing)

4 - 3 screw plugs, M16x1 (when removing, collect emerging coolant, when installing, replace sealing ring)

5 - 10 hexagon-head bolts M6x25

6 - 2 seals for distributor pipe (when installing, clean sealing faces and replace seal)

7 - 4 sealing rings (when installing, grease with Kluber Syntheso GLEP 1

8 - Lower cooling water tube

See also:
• 97 84 IN Fuse carrier - as of MY 2003 (All Models)
