Installing sun visor
Installation Location
Scheme 513
1. Install sun visor.
1.1. Move sun visor -9- into installation position ( -arrow A- ). (Scheme 513)
1.2. Insert plug for mirror light -11- ( -arrow B- ). (Scheme 513)
1.3. Clip in sun visor -9- completely ( -arrow A- ). (Scheme 513)
Scheme 514
2. Install pivot bearing.
2.1. Screw in fastening screws -8-. (Scheme 514)
Scheme 515
3. Clip in cover for pivot bearing.
3.1. Align and engage cover for pivot bearing -7- 4 ( -arrow C- ). (Scheme 515)
Scheme 516
4. Move adjustable sun visor to lateral position.
4.1. Swivel adjustable part of the sun visor -1- towards roof frame ( -arrow D- ). (Scheme 516)
4.2. Leave sun visor -5- in unfolded position. (Scheme 516)
Scheme 517
5. Install mounting saddle.
5.1. Insert lock -6- in mounting saddle -3- ( -arrow E- ). (Scheme 517)
5.2. Engage mounting saddle -3- at the top on the roof liner ( -arrow F- ). (Scheme 517)
5.3. Swivel mounting saddle -3- forwards towards the windscreen and clip in place ( -arrow G- ). (Scheme 517)
5.4. Pivot sun visor -5- towards roof liner (normal position) ( -arrow H- ). (Scheme 517)
Scheme 518
6. Fasten mounting saddle.
6.1. Unclip cover cap -2- on the mounting saddle -3- with a screwdriver ( -I- ) and unfold ( -arrow K- ). (Scheme 518)
6.2. Screw in fastening screw -4- and tighten. (Scheme 518)
6.3. Close -2- cover cap -arrow L-. (Scheme 518)
Scheme 519
7. Move swivelling sun visor to original position
7.1. Swivel adjustable part of the sun visor -1- towards windscreen ( -arrow M- ). (Scheme 519)
