Removing ignition switch
Installation Location
Scheme 1
Scheme 2
1. Carefully lift rubber sleeve on the ignition starter switch -arrow A- using a screwdriver, for example, and remove it. (Scheme 2)
2. Carefully unclip molding for dashboard -arrow B- with a plastic spatula. Observe the two upper lugs when doing do. (Scheme 2)
Scheme 3
3. Turn union nut using a narrow plastic spatula, for example, or using the special wrench T10152 tool and unscrew the ring from the ignition starter switch.
4. Press ignition switch inwards and remove towards the bottom.
Scheme 4
5. Press connector -arrow- and pull off from ignition starter switch. (Scheme 4)
Scheme 5
1. Connect the connector to the ignition starter switch until it engages firmly.
Scheme 6
2. Position ignition starter switch in the dashboard. Position union nut, re-adjust switch and tighten union nut using wrench T10152 . --> Tightening torque: 1 ftlb.
Scheme 7
3. Check clips on the molding for the dashboard for damage and replace if necessary.
4. Position molding and press onto the dashboard until the clips engage.
