Installing transfer box control module
Installation Location
Scheme 38
1. Insert the control unit -A- until the locking tabs -B- are felt to engage. (Scheme 38)
Scheme 39
2. Insert the two connectors -A- and press in the locking mechanism -B- until it is felt to engage. (Scheme 39)
3. Place the support with the two control units in the installation position -C-. (Scheme 39)
Scheme 40
4. Move seat all the way back and tighten the support with the fastening screw.
Scheme 41
Note. Only for vehicles with telephone
5. Position the support for the telephone control unit and screw down using the three fastening nuts.
6. For vehicles with a telephone, install the telephone control unit. Refer to 91 90 19 Removing and installing control unit for telephone - as of MY 2003 (All Models) .
7. Clip in right front seat trim and install drawer.
Designation Type Number Explanation shop-made tool commercially available tool pressure piece commercially available tool t10181 striker commercially available tool vw 771/1 extraction tool commercially available tool vw 771/37
