Installing pressure switch
1. Replace the O-ring on the pressure switch and wet it with refrigerant oil.
Scheme 277
2. Screw pressure switch onto refrigerant line and tighten with an open-ended wrench. Counter with a second open-ended wrench. --> Tightening torque: 3.5 ftlb.
3. Push electrical plug onto pressure switch until it clicks into place.
1. Fill in refrigerant. > 870317 Evacuating and filling in refrigerant - chapter on "filling"
2. Install cowl panel cover. Refer to 66 44 19 Removing and installing cowl panel cover - as of MY 2003 (All Models) .
3. Install wiper linkage. Refer to 92 15 19 Removing and installing wiper motor - as of MY 2003 (All Models) .
