Installing back seat
Installation Location
| CAUTION | Danger of material damage to seat bolts! |
> The fastening screws for seats are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M 10 tap!
Scheme 119
1. To position the rear seats, unfold hinge parts on the rear seats and place seats in a raised position -->. see scheme 128
Scheme 120
Scheme 121
Scheme 122
2. Screw in fastening screws -3-, -3- and -3- and tighten to the specified tightening torque. --> Tightening torque: 50 (37 ftlb.) Nm +10 (7.5 ftlb.) Nm. (Scheme 119), (Scheme 120), (Scheme 121).
Scheme 123
3. Only for vehicles with seat heater: Clip in plug -Arrow A-. (Scheme 122)
4. Push on the connector -Arrow B- until the locking tabs engage audibly -arrows-. (Scheme 122)
5. Fold down rear seats -1, 2- and lock them. (Scheme 123)
