Securing lock mount

Installation Location

Scheme 288

Scheme 288

1. Slide the lock mount into its installation position.

1.1. To prevent damage to the accessories, slide the lock mount back into the installation position on both sides evenly.

Scheme 289

Scheme 289

2. Screw in -5- fastening screws. see scheme 134

2.1. Screw in fastening screws on both sides of the vehicle and tighten slightly.

Scheme 290

Scheme 290

3. Unscrew the service fastening screws -4-. (Scheme 288)

3.1. Undo service fastening screws on both sides of the vehicle.

Scheme 291

Scheme 291

4. Screw in the fastening screws -3- and tighten slightly. (Scheme 289)

4.1. Screw in fastening screws on both sides of the vehicle and tighten slightly.

4.2. Position the lock mounts according to the existing impressions.

Scheme 292

Scheme 292

5. Fix the lock mount in its installation position

5.1. Screw in fastening screws -6 and 7- on both sides of the vehicle and tighten finger-tight. (Scheme 290)

6. Adjust the lock mount.

7. Tighten the fastening screws on the lock mount.

7.1. Tighten fastening screws -3-, -5-, -6 and 7- to the specified tightening torque. --> Tightening torque: 6.5 Nm +/-0.5 Nm --> Tightening torque: 9 (6.5 ftlb.) Nm +/-1 (0.5 ftlb.) Nm --> Tightening torque: 65 (48 ftlb.) Nm +/-10 (7.5 ftlb.) Nm. (Scheme 291), (Scheme 292) and see scheme 140.

8. Install front spoiler guide rails at the sides.

Scheme 293

Scheme 293

9. Connect the air guides.

9.1. Connect the air guides at the air cleaner housings -8-. see scheme 141

Scheme 294

Scheme 294

10. Fasten charge air cooler Cayenne Turbo only

10.1. Insert spacers -17-. see scheme 142

10.2. Screw in fastening screws -16- and tighten to the specified tightening torque. --> Tightening torque: 9 (6.5 ftlb.) Nm +/-1 (0.5 ftlb.) Nm. see scheme 142

Scheme 295

Scheme 295

11. Install side air guides. Cayenne Turbo only

11.1. Position the side air guide -15- and move it to the center of the vehicle until it engages. (Scheme 293)

11.2. Position and clip in air sensor wiring harness -14-. (Scheme 293)

12. Install front lid seal.

Scheme 296

Scheme 296

13. Connect the electric plug connection -9-. (Scheme 294)

13.1. Connect the electric plug connection on the left side of the vehicle.

14. Install the rubber covers.

Scheme 297

Scheme 297

14.1. Put on the right -1- rubber cover from above and press in the rubber tabs. (Scheme 295)

Scheme 298

Scheme 298

14.2. Put on the left -2- rubber cover from above and press in the rubber tabs. (Scheme 296)
