Installing frame for sunroof
Installation Location
Scheme 57
1. Put on frame for sunroof.
Scheme 58
1.1. Insert the sliding roof frame -1- with an assistant through the rear lid opening into the passenger compartment. (Scheme 56)
Note. The punches have a diameter of 10 mm or 12 mm.
1.2. Position frame for sliding door -1- on the roof frame and attach to the locating bores with punches -6 and 7-. (Scheme 57)
Scheme 59
1.3. Screw in fastening screws -4a, 4b- and -4c to 4e- and tighten so that the frame for the sliding roof can still be moved slightly. (Scheme 58), see scheme 82.
Scheme 60
Installation Location
Scheme 61
2. Tighten the fastening screws -4- in the sequence shown -4a, 4b- and -4c to 4e-. --> Tightening torque: 8 (6 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm. (Scheme 59), (Scheme 60), (Scheme 61).
Scheme 62
3. Push electric plug connection -5- onto sunroof drive until locking tabs audibly engage. see scheme 86
Scheme 63
4. Remove fixing devices.
4.1. Remove punch -6- and -7-. see scheme 87, (Scheme 62).
Scheme 64
Scheme 65
5. Connect water drain hoses -2- at the front. (Scheme 63)
Scheme 66
6. Connect water drain hoses -3- at the rear. (Scheme 64)
Designation Type Number Explanation hook VW-tool 3370
