Removing middle sensor
Note. Accessibility is limited. If the carpet is pulled back too far, it will tear at the edges.
1. Lift up the carpet towards the rear.
Scheme 92
| WARNING | Danger of injury and damage to property as a result of incorrect handling of airbag sensors! Risk of confusing the front, middle and rear sensors, since they do not differ in appearance. |
> Always observe the safety regulations for handling airbag units. Refer to 69 AW Safety regulations for handling airbags and... - as of MY 2003 (All Models) .
> Remove ignition key. Disconnect battery. Route or isolate ground strap so that all contact with a ground carrier (e. g. body, seat frame) is avoided. Refer to 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan)
> Before the connector is disconnected from the sensor, always wait for 1 minute before disconnecting the battery.
2. Push in lock -2- on plug for sensor -1-, until this perceptibly engages -arrow A-. (Scheme 92)
3. Release locking mechanism on the latch -2- -arrow B- and pull off plug from sensor -1- -arrow C-. see scheme 127
Scheme 93
4. Unscrew the two fastening screws -4- and remove the sensor. (Scheme 93)
Scheme 94
| WARNING | Danger of injury and damage to property as a result of incorrect handling of airbag sensors! Risk of confusing the front, middle and rear sensors, since they do not differ in appearance. |
> Always observe the safety regulations for handling airbag units. Refer to 69 AW Safety regulations for handling airbags and... - as of MY 2003 (All Models) .
> Remove ignition key. Disconnect battery. Route or isolate ground strap so that all contact with a ground carrier (e. g. body, seat frame) is avoided. Refer to 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan)
> Before the connector is disconnected from the sensor, always wait for 1 minute before disconnecting the battery.
1. Push in lock -2- on plug for sensor -1-, until this perceptibly engages -arrow A-. (Scheme 94)
2. Release locking mechanism on the latch -2- -arrow B- and pull off plug from sensor -1- -arrow C-. see scheme 130
Scheme 95
3. Unscrew the two fastening screws -4- and remove the sensor. (Scheme 95)
