Installing front power windows Porsche Cayenne S I

Installing front power windows

Installation Location

1. Installing power windows

Scheme 65

1.1. Place the power window on the door unit carrier as shown. Make sure the cable is in the correct position ( -arrow A- ). (Scheme 65)

1.2. Clip in power window gear -3- in the door sub-frame. (Scheme 66)

1.3. Fix guide rails -2- with 2 rivets each -1- and rivet with the door unit carrier. (Scheme 66)

Scheme 66

Scheme 67

1.4. Clip in cable to retaining clip -4-. (Scheme 67)

1.5. Apply lubricant (grease) to the guide rails -2- and move sliding pads -5- manually. see scheme 75

1. Install front door window

1.1. 64 40 19 Removing and installing front door window - as of MY 2003 (All Models)

2. Install front door sub-frame

2.1. Refer to 57 30 19 Removing and installing front door sub-frame - as of MY 2003 (All Models) .

Remove front door trim panel. Refer to 70 59 19 Removing and installing front door trim panel - as of MY 2003 (All Models) .

Scheme 68

Note. When removing the door trim, plug 6 -5- on the window regulator motor is disconnected. (Scheme 68)

1. Unscrew the three fastening screws -1-. (Scheme 68)

2. Press on the lock of the plugs -Arrows 2, 3 and 4- and remove the plugs. (Scheme 68)

Scheme 69

3. Pull the window regulator motor out of the teeth.

Scheme 70

1. Position window regulator motor and push into the teeth.

Scheme 71

2. Insert plugs -Arrows 2, 3 and 4- on control unit for window regulator motor, until plugs perceptibly engage. (Scheme 71)

3. Insert the three fastening screws -1- and tighten them. --> Tightening torque: 2.0 ftlb.. (Scheme 71)

Install front door trim panel. Refer to 70 59 19 Removing and installing front door trim panel - as of MY 2003 (All Models) .
