Installing front power windows
Installation Location
Scheme 77
1. Fold power windows -1- together and insert through the door opening -arrows-. (Scheme 76)
Scheme 78
| CAUTION | Noises on the power windows due to interfacing the window lifter rails! |
> When moving the window lifter rails, they must be adjusted in parallel both during the first installation as well as during subsequent adjustment.
2. First position the lower fastening points of the power windows -1- to the dimension -X = 5 mm- and tighten with fastening nuts - 2-. Tightening torque --> Final tightening: 7 ftlb. see scheme 91
Scheme 79
3. Then screw down the upper fastening points of the power windows -1- with the fastening nuts -2-. Tightening torque --> Final tightening: 7.2 ftlb. (Scheme 77)
4. Clip in cable at retaining clip -1-. (Scheme 78)
5. Fit rubber sleeves -1-. (Scheme 79)
1. Install door sub-frame. Refer to 57 30 19 Removing and installing door unit carrier - as of MY 2005 (All Models) .
2. Install front door window. > 644019 Removing and installing front door window - chapter on "installing"
1. Remove door sub-frame. Refer to 57 30 19 Removing and installing door unit carrier - as of MY 2005 (All Models) .
2. Remove front door window. > 644019 Removing and installing front door window - chapter on "removing"
Installation Location
1. Remove rubber sleeves -1-. see scheme 96
2. Unclip cable at retaining clip -1-. see scheme 97
3. Unscrew fastening nuts -2- on power windows -1-. see scheme 98
4. Fold power windows -1- together and remove through the door opening -arrow-. see scheme 99
Installation Location
Note. When replacing the power window unit, make sure that the correct position of the lower limit stop is selected for the relevant vehicle model.
- There are three bores lying one above the other with the screwed-on limit stop in the front power window unit rail.
- The limit stop must be fitted in the top bore for the 987 model.
Scheme 80
Installation Location
1. Fold power windows -1- together and insert through the door opening -arrows-. (Scheme 80)
| CAUTION | Noises on the power windows due to interfacing the window lifter rails! |
> When moving the window lifter rails, they must be adjusted in parallel both during the first installation as well as during subsequent adjustment.
2. First position the lower fastening points of the power windows -1- to the dimension -X = 5 mm- and tighten with fastening nuts - 2-. Tightening torque --> Final tightening: 7 ftlb. see scheme 104
3. Then screw down the upper fastening points of the power windows -1- with the fastening nuts -2-. Tightening torque --> Final tightening: 7.2 ftlb. see scheme 105
4. Clip in cable at retaining clip -1-. see scheme 106
5. Fit rubber sleeves -1-. see scheme 107
1. Install door sub-frame. Refer to 57 30 19 Removing and installing door unit carrier - as of MY 2005 (All Models) .
2. Install front door window. > 644019 Removing and installing front door window - chapter on "installing"
Designation Type Number Explanation PIWIS tester special tool P 9718
