Gap dimensions, hardtop
Note. Set gap dimensions on the lids, doors and covers, or accessories in accordance with the gap specifications. Given a clearance in the opening that is too great or too small, the movable body or the accessories must be centerd accordingly. Ensure that the gaps do not taper or do not narrow at local points. The given values are guidelines which should be observed as far as possible. The guidelines apply to repair and assembly work. Use star gauges to measure the gap dimensions, Star gauges for body gap dimensions NR.127-1
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Windscreen frame to hardtop | | Gap dimension A | 6.5 mm | +/-1 mm | |
| Windscreen frame to hardtop | Convertible top only lowered | Gap dimension B | 1.5 mm | | |
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Windscreen frame to outer hardtop | | Gap dimension A | 5.8 mm | | |
| Windscreen frame to outer hardtop | Convertible top only lowered | Gap dimension B | 1.5 mm | | |
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Hardtop to side window | | Gap dimension A | 7.7 mm | +/-3 mm | |
| Hardtop to side window | | Gap dimension B | 5.2 mm | | |
Scheme 885
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Roof joint strip to hardtop | Only lowered | Gap dimension A | 0.7 mm | | |
Scheme 886
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Hardtop body to cover | | Gap dimension A | 5.5 mm | +/-3.5 mm | |
Scheme 887
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Hardtop to side convertible-top compartment lid | | Gap dimension A | 5.5 mm | +/-3.5 mm | |
Scheme 888
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|
| Hardtop to convertible-top compartment lid | | Gap dimension A | 5.5 mm | +/-3.5 mm | |
| Designation | Type | Number | Explanation | |
|---|
| Primer | Commercially available tool | | | |
Scheme 889
Scheme 889: Processing structural body adhesive
| Item | Designation | Source | Explanation |
|---|
| A | Primer | > "See Parts Catalogue in Main Group 8 " | |
| B | Processing gun | > "See Parts Catalogue in Main Group 8 " | |
| C | Betamate 2096 adhesive set | > "See Parts Catalogue in Main Group 8 " | |
| Item | Designation | Item | Designation |
|---|
| B1 | Piston rod | C1 | Double cartridge |
| B2 | Gun grip | C2 | Processing nozzle |
