Installing double sealing ring
1. Check seat of sealing ring in transmission housing for damage.
2. Thinly coat outer circumference and sealing lips of sealing ring with Vaseline.
Scheme 62
3. Push double sealing ring on so that the projecting sealing lip is pointing towards the pressure piece 3383 .
Scheme 63
4. Drive double sealing ring into the transmission housing up to the stop with pressure piece 3383 .
1. Install differential. > 390919 Removing and installing differential - section on "Installing" [987310 987311] > 390919 Removing and installing differential - section on "Installing" [987120 987121 987320 987321]
2. Top up oil for final drive and perform all assembly work described. > 399055 Changing oil for final drive
3. Retaining device P 9624/1 must then be removed from cross member.
4. Fit restraining cables to cross member.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Restraining cable | Fastening nut between restraining cable and cross member | Tightening torque | 23 (17 ftlb.) Nm |
5. Install support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
6. Install right wheel. Refer to 44 05 19 Removing and installing wheel - as of MY 2005 (All Models) .
7. Lower the vehicle.
Designation Type Number Explanation pressure piece VW-tool 3382 hook VW-tool VW 681
Scheme 64
1. Raise the vehicle at the prescribed jacking points. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
2. Remove support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
3. Remove short halfshaft flange. > 392519 Removing and installing halfshaft flange - section on "Removing" [987310 987311] > 392519 Removing and installing halfshaft flange - section on "Removing" [987120 987121 987320 987321]
Scheme 65
1. Remove sealing ring with hook VW 681 .
