Wiring diagram: Body control modules — On-board computer circuit Porsche Boxster 987

Components on these wiring diagrams 22

Click a component to highlight it on every diagram it appears on.

• Automatic Light Switch
• Current Distributor Fuse
• Emergency Light Term 15
• Fog Light Switch
• Front Cover Opener Button Rear Cover Opener Button Rear Window Unlocking Button
• Front End Control Unit
• Fuse Holder B Fuse
• Gateway Control Unit
• Gear Running Wake Up Washing Fluid Pump Washing Fluid Pump +
• Ground Connection 1
• Inside Light Term 30 Inside Light Sw Term 30 Rear Spoiler Mod Button
• Left Seat Heater Left Seat Heater +
• Mfi-Di Control Unit
• On-Board Computer Network Control Unit
• Pas Control Unit
• Rain Sensor + Rain Sensor Siganl Rain Sensor
• Rear Control Unit
• Rear Spoiler Func Light
• Sport Mode Func Light Reserve Light Func 1
• Term 15
• Term 15 Start Consumers
• Windshield Wiper Motor Parking Sw
