Subsequent work
1. Install door unit carrier. > 573019 Removing and installing door unit carrier - chapter on "installing"
1. Remove door handle. > 571119 Removing and installing door handle - chapter on "Removing"
2. Remove microswitch for window opening controls. Refer to 64 37 19 Removing and installing microswitch for window opening controls - as of MY 2005 (All Models) .
Scheme 110
1. Press out circlip -1-, pull pin -2- out of the handle and remove actuating shaft -3-. (Scheme 110)
2. Pull pin rod -4- out of the handle liner -9- and separate handle -8- from the handle liner. (Scheme 110)
3. Remove return spring -6-, eccentric -5- and sleeve -7-. (Scheme 110)
4. Pull buffer -10- out of the handle -8-, check it and replace if necessary. (Scheme 110)
1. Install microswitch for window opening controls. Refer to 64 37 19 Removing and installing microswitch for window opening controls - as of MY 2005 (All Models) .
2. Install door handle. > 571119 Removing and installing door handle - chapter on "Installing"
Designation Type Number Explanation assembly tool VW-tool T10118
1. Remove door unit carrier. > 573019 Removing and installing door unit carrier - chapter on "removing"
Installation Location
1. Press locking tabs -arrow A- and move sliding part -1- -arrow B-. see scheme 29
2. Unclip the connection piece -2- from the actuating shaft -3-. see scheme 29
