Scheme 7
Scheme 8
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Removing seat rail cover -2A-. (Scheme 7) | Unscrew the sheetmetal screws out of the seat rail cover at the front -2A-2A-. (Scheme 7) |
| 2 | Removing seat rail cover -2B-. (Scheme 7) | Insert a screwdriver under the locking tabs and press lightly upwards. -2B-. (Scheme 7) CAUTION: 2B-. (Scheme 7) Locking tabs can break. -2B-. (Scheme 7) Pull front seat rail cover -2B-. (Scheme 7) |
| 3 | Undoing seat screws at front | Move seat to its rear limit position and undo the front M10 x 28 Torx screws -3-. (Scheme 7) |
| 4 | Undoing seat screws at rear | Move seat to its front limit position and undo the M10 x 28 Torx screws -3-. (Scheme 7) |
| 5 | Disconnecting the electrical plug connection | Release plug connector locking device on the side -arrow-. (Scheme 7) |
| CAUTION |
|---|
| 2B-. (Scheme 7) Locking tabs can break. -2B-. (Scheme 7) Pull front seat rail cover -2B-. (Scheme 7) |
REMOVING PROCEDURE FOR FRONT SEAT
Scheme 9
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Connecting electrical plug connection | Join the plug connection -4-arrow-. (Scheme 9) |
| 2 | Fitting seat screws at rear | Position seat rails on the seat baseframe, screw the rear M10 x 28 Torx screws -3-65 N.m-. (Scheme 9) |
| 3 | Fitting seat screws at front | Move seat to its rear limit position, screw the front M10 x 28 Torx screws -3-65 N.m-. (Scheme 9) |
| 4 | Fitting seat rail cover -2B-. (Scheme 9) | Push seat rail cover -2B-. (Scheme 9) |
| 5 | Fitting seat rail cover -2A-. (Scheme 9) | Push seat rail cover -2A-. (Scheme 9) |
INSTALLING PROCEDURE FOR FRONT SEAT
