Electrical Component Locator — Porsche Boxster S 987 рестайлинг (2006-2009)

BUZZERS, RELAYS & TIMERS

Component	Location
A/C Compressor Relay (1)	On relay support 2. (Scheme 18)
Convertible Top Closed Relay (5)	On relay support 1. (Scheme 17)
Convertible Top Open Relay (3)	On relay support 1. (Scheme 17)
Electric Fuel Pump Relay (8)	On relay support 1. (Scheme 17)
Emergency Power Supply Relay 2 (4)	On relay support 1. (Scheme 17)
Engine Compartment Blower Relay (8)	On relay support 2. (Scheme 18)
Headlight Washing Relay (14)	On relay support 1. (Scheme 17)
Heater Relay (12)	On relay support 1. (Scheme 17)
MFI+DI Relay (11)	On relay support 1. (Scheme 17)
Rear Window Heating Relay (7)	On relay support 1. (Scheme 17)
Secondary Air Pump Relay (2)	On relay support 2. (Scheme 18)
Start Lock Relay (15)	On relay support 1. (Scheme 17)
Terminal 15 Relay (16)	On relay support 1. (Scheme 17)
Terminal 86S Relay	On relay support 1. (Scheme 17)

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

Component	Location
Fuses Support	Under left side of dash, at kick panel. (Scheme 12)
Maxi Fuse Rear Window Defogger	Left side of engine compartment, on fuses support. (Scheme 12)
Maxi Fuse Secondary Air Pump	Left side of engine compartment, on fuses support. (Scheme 12)
Relay Support 1	Under left side of dash, in footwell. (Scheme 16)
Relay Support 2	On left side of rear luggage compartment. (Scheme 16)

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

Component	Location
CU Airbag	Under center console. (Scheme 7)
CU Front End	At right side of front luggage compartment. (Scheme 1)
CU On Board Comp. Network	Under left side of dash. (Scheme 13)
CU Parking Assistant	Under left seat. (Scheme 15)
CU PAS	Behind left side of dash. (Scheme 6)
CU PASM (Damptronic Control Unit)	At right kick panel. (Scheme 10)
CU PSM (Porsche Stability Management Control Unit)	Left side of front luggage compartment. (Scheme 9)
CU Rear	Under left seat. (Scheme 3)
Current Distributor	Behind right side of dash. (Scheme 12)
CU Telephone	Under right seat. (Scheme 14)
CU Tiptronic	Right rear of engine compartment. (Scheme 8)
CU Tire Pressure Control	Left side of front luggage compartment. (Scheme 11)
Diversity Unit (Left/Right)	On respective "A" pillar.
Electric Fuel Pump Control Unit	In front luggage compartment.
Gateway Control Unit	Left kick panel.
MFI-DI Control Unit	On left side of rear luggage compartment.
PAS (Driver Recognition) Control Unit	Under dash, left of steering column.
Rear Window Module	Left front of engine compartment. (Scheme 3)
Seat Memory Control Unit (Left/Right)	Under respective left/right seat.
Transmission Control Unit	On gear box.

CONTROL UNITS LOCATION

MOTORS

Component	Location
Cooling Water Blower (Left/Right)	Under respective front headlight.
Drive Spoiler	On rear flap. (Scheme 3)
Drive Sun Roof	Front center of sun roof. (Scheme 3)
Engine Compartment Cleaner Fan	On left front side of engine compartment.
Fuel Pump	In fuel tank.
Headlight Washing Fluid Pump	On washer fluid reservoir.
Hooks Actuator	Front of front luggage compartment. (Scheme 1)
Intake Pipe Change-Over	Front middle of engine.
Intake Pipe Flap	Front middle of engine.
Midi Fuse Fan	Right front of luggage compartment. (Scheme 12)
Secondary Air Pump	Net to intake bridge.
Tailgate Unlocking Actuator	Center rear of tailgate. (Scheme 3)
Windshield Washing Fluid Pump	On left side of front luggage compartment, in washer fluid reservoir.
Windshield Wiper Motor	In left rear corner of front luggage compartment.

MOTORS LOCATION

SENDING UNITS & SENSORS

Component	Location
AHVAC Sensor (Left Front)	On left front semi-trailing arm. (Scheme 1)
AHVAC Sensor (Left Rear)	On left rear semi-trailing arm. (Scheme 1)
Air Bag Front Sensor (Right)	On longitudinal support, in front luggage compartment.
AY Sensor	Under floor panel of center console. (Scheme 9)
Brake Pad Wear Contacts	At wheel assemblies. (Scheme 9)
Camshaft Sensor (2)	At left rear & right front of engine.
Cooling Water Sensor	In water box.
Engine Speed Sensor	On left side of clutch bell housing.
Engine Speed Sensors	At wheel assemblies. (Scheme 9)
Front Sensors (Air Bag)	On longitudinal supports, in front luggage compartment. (Scheme 7)
Fuel Pump/Level Sensor	Under battery, in fuel tank.
Hot-Film Air Mass Meter	Left side of engine compartment.
Inside Blower Temperature Sensor	Behind right side of dash.
Interior Sensor (Cabrio)	Under center of parcel shelf. (Scheme 3)
Interior Sensor (Coupe)	In center console. (Scheme 3)
Knock Sensors	On engine block.
NTC Coolant Temperature Sensor	On engine.
NTC Engine Compartment Temperature Sensor	Middle of engine.
Oil Temperature Sensor	On engine oil pan.
Outside Temp. Sensor	Behind right side of front bumper. (Scheme 1)
Oxygen Sensor (Left/Right)	In left/right exhaust manifold.
Pedal Valve Sensor	Under accelerator pedal.
Rain Sensor	In windshield.
Sensor Cooling Water Pressure	In water box. (Scheme 5)
Side Airbag Sensor (Left/Right)	At respective left/right "B" pillar. (Scheme 7)
Sun Sensor	Under top center of dash. (Scheme 3)
Tilt Sensor	Left side of front luggage compartment. (Scheme 3)
Ultrasonic Sensors No. 1 & 2	In right side of rear bumper. (Scheme 15)
Ultrasonic Sensors No. 3 & 4	In left side of rear bumper. (Scheme 15)
Vertical Sensor (Left Rear/Right Front)	At respective absorbers. (Scheme 10)
Weight Recognition Sensor	Under passenger seat.
Wheel Speed Sensor (4)	At respective wheel carriers.

SENDING UNITS & SENSORS LOCATION

SOLENOIDS & SOLENOID VALVES

Component	Location
Absorbers Valve (4)	Low on respective shock absorbers. (Scheme 10)
Actuator Tank Cover	Right front fender. (Scheme 2)
Air Conditioning Compressor	Left front of engine. (Scheme 5)
Camshaft Adjustment	Top of engine.
DMTL Valve	Right rear of front luggage compartment.
Fuel Injectors	On intake manifolds.
Ignition Lock	In steering column, at ignition switch. (Scheme 6)
Secondary Air Valve	Next to intake bridge.
Tank Venting Valve	Near fuel fill flap.
Throttle Valve	Middle of intake manifold.
Valve-Lift Control	On cylinder head cover.

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

Component	Location
Backup Light Switch	On top right of transmission. (Scheme 13)
Brake Fluid Level Control Switch	In brake fluid reservoir.
Button Emergency Open	Left side of front luggage compartment. (Scheme 1)
Clutch Interlock Switch	At clutch pedal.
Clutch Switch	At clutch pedal.
Cooling Water Level Switch	In expansion tank.
Micro Switch Locking Hook Roof (Cabrio)	Center front of roof. (Scheme 3)
Microswitch Luggage Compartment Lock	Front of front luggage compartment. (Scheme 1)
Micro Switch Tailgate Lock	Center rear of tailgate. (Scheme 3)
Oil Pressure Switch	Left side of engine.
Parking Brake Contact	At base of hand brake lever. (Scheme 9)
Stoplight Switch	On brake pedal linkage.
Sun Roof Switch	Center front of roof. (Scheme 3)
Transmission Switch Lifting	On transmission. (Scheme 8)
Washing Fluid Level Switch	In washing fluid reservoir. (Scheme 4)

SWITCHES LOCATION

MISCELLANEOUS

Component	Location
Airbag Driver's Side 1 & 2	In steering wheel. (Scheme 7)
Airbag Passenger's Side 1 & 2	Behind right side of dash. (Scheme 7)
Alarm Horn	On left side of front luggage compartment, left of battery. (Scheme 3)
Alarm Siren	On left side of front luggage compartment, left of battery. (Scheme 3)
Amplifier Antenna (Left/Right)	In respective "A" pillar. (Scheme 13)
Antenna GPS	Right rear of front luggage compartment. (Scheme 13)
Antenna (Tire Pressure Control) (4)	In respective wheelwell. (Scheme 11)
Audio Amplifier (Option Pack)	In front luggage compartment.
Battery	In water box. (Scheme 12)
Belt Lock (Left/Right)	At respective seat belt buckle. (Scheme 7)
Bridge Plug 1 Terminal 31 (9)	On relay support 1.
Bridge Plug 2 Terminal 15 (9)	On relay support 1. (Scheme 17)
Diagnosis Connector	Below left side of dash.
Diversity Antenna (Left/Right)	In respective "A" pillar.
Emergency Power Pin	On fuses support, under left side of dash, at kick panel.
Exterior Temperature Transmitter	Behind center of front bumper.
Exterior Temperature Transmitter	Attached to rib of PV part.
Head Airbag (Left/Right)	In respective door. (Scheme 7)
HFM	Right side of engine compartment.
Homelink Transmitter	Right front of front trunk. (Scheme 2)
Ignition Coils	On cylinder head cover.
Microphone Free-Handed Speaking	Under top left side of dash. (Scheme 13)
More Belt-Tautly (Left/Right Seat Belt Tensioner)	At respective "B" pillar. (Scheme 7)
Navigation Computer	Front of luggage compartment.
PCM (Porsche Communications Management)	In center console.
Roll Bar Magnet	On right side of roll bar.
Telephone Antenna	Right rear of front luggage compartment. (Scheme 14)
Thorax Airbag In Seat (Left/Right)	In respective left/right seat. (Scheme 7)
Two-Tone Horns	Near right headlight assembly. (Scheme 1)

MISCELLANEOUS LOCATION

CONNECTORS

Component	Location
X2/1 (Black, 30 Pin)	At left front side of engine compartment.
X2/2 (Black, 30 Pin)	At left front side of engine compartment.
X3/1 (Natural, 12 Pin)	At left front side of engine compartment.
X3/2 (Blue, 12 pin)	At left front side of engine compartment.
X11 (12 Pin)	At base of left "A" pillar.
X12 (12 Pin)	At base of right "A" pillar.
X16 (Black, 19 Pin)	Under front of left seat.
X17 (Black, 19 Pin)	Under front of right seat.
X59 (Black, 12 Pin)	At left front side of engine compartment.

CONNECTORS LOCATION

GROUNDS

Component	Location
GP Air Bag	Under center console.
GP Electronics	At left side of dash.
GP PSM	At front left side of luggage compartment.
GP1	In front of right front fender.
GP2	In front of left front fender.
GP3	Behind left side of dash.
GP4	At center of dash.
GP5	At right side of dash.
GP6	Below right seat.
GP7	Below left seat.
GP8	At left side of engine compartment.
GP9	At left side of engine compartment.
GP10	At left side of engine compartment.
GP11	At left side of engine compartment.
GP12	At left side of engine compartment.
GP13	At battery.
