Installing rain sensor
Note. An adhesive pad must be used when reinstalling the rain sensor. When fitting the adhesive pad, make sure there is no air trapped between the windscreen and the adhesive pad or between the adhesive pad and the rain sensor. When installing the adhesive pad, the temperature of the windscreen, rain sensor and adhesive pad must be approx 20°C. Carefully heat the windscreen with a hot-air gun for example. Do not touch the adhesive surface of the sensor with your fingers. If the sensor is new, remove the protection cap before sticking the sensor on to the windscreen. When sticking on a new sensor, make sure that no air pockets are caught between the gel and the windscreen. Air pockets could impair the function of the sensor. Sensor, orientation lights, wires and wiring ducts are spare parts.
Limited functionality of the rain sensor if the following points are not observed: > Please observe note "An adhesive pad must be used when reinstalling the rain sensor".
Note. If the removed rain sensor is to be reinstalled, the surfaces must be free of adhesive residues. Do not use harsh cleaning agents. Stick the adhesive pad onto the rain sensor at a temperature of approx. 20°C.
1. Press the rain sensor -6- onto the windscreen. (Scheme 11)
Scheme 11
2. Push and press holder -5- onto the rain sensor until it engages. (Scheme 12)
Scheme 12
3. Push rear-view mirror -4- onto the mirror holder from below. (Scheme 13)
Scheme 13
4. Join the plug connection -3- and insert it into the mirror base. (Scheme 14)
Scheme 14
5. Insert orientation light into the cover.
Scheme 15
6. Join both covers -1- , ensuring that the orientation light is positioned correctly.
Scheme 16
7. Push the electrical plug connection together -1- until the plug is felt to engage. (Scheme 17)
Scheme 17
8. Engage holder -2- for the electric line and push line in behind the roof liner. (Scheme 18)
Scheme 18
9. Tighten fastening screws -1- and clip in both covers. (Scheme 19)
