Removing compressor/condenser line
Note. Close off all lines and connections using suitable plugs during removal. Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if necessary.
Installation Location
Scheme 162
A - Compressor/condenser line
1. Unscrew fastening screw -1- on compressor, pull out line on compressor and remove it from support -7-. (Scheme 163)
Scheme 163
2. Unscrew fastening nut -5- on cable holder, open cable holder and pull line out of rubber mounting -6-. (Scheme 163)
3. Unscrew fastening screw -3- on connection point and pull out line. (Scheme 163)
4. Remove line downwards from the engine area.
