REMOVE THE TIPTRONIC CONTROL UNIT Porsche Boxster S 986 рестайлинг

Automatic Transmission, Controls, Case 5 illustrations ~180 words

REMOVE THE TIPTRONIC CONTROL UNIT

Note. The Tiptronic control unit is located in the rear luggage compartment on the bulkhead. The ignition key must be removed before starting the assembly work. If the Tiptronic control unit is replaced, observe the points under coding the control unit. See CODING THE TIPTRONIC CONTROL UNIT .

Scheme 70

Scheme 70: REMOVE THE TIPTRONIC CONTROL UNIT
Scheme 70: REMOVE THE TIPTRONIC CONTROL UNIT

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72
  1. Open rear luggage compartment lid and lever out the clips for the carpet lining using the removal tool. See «TOOLS»(/porsche/boxster-s/986-2002-2004/remont/automatic-trans/#automatic-transmission-controls-case) .
  2. Fold over the carpet lining and unscrew the 3 fastening nuts for the Tiptronic control unit.
  3. Lift out the control unit and open the connector -arrow- and remove.
  4. Remove the control unit.

Scheme 73

Scheme 73: INSTALL THE TIPTRONIC CONTROL UNIT
Scheme 73: INSTALL THE TIPTRONIC CONTROL UNIT

Scheme 74

Scheme 74
Scheme 74
  1. Connect the connector on the control unit and insert the closing bracket until it engages.
  2. Position control unit and secure with the fastening nuts. Tightening torque: 10 Nm (7.5 ft.lb).
  3. Fold back the carpet lining into position and fasten with the clips.
  4. Program the Tiptronic control unit with the Porsche System Tester. See «CODING THE TIPTRONIC CONTROL UNIT»(/porsche/boxster-s/986-2002-2004/remont/automatic-trans/#automatic-transmission-controls-case__coding-the-tiptronic-control-unit) .
