Camber and Caster adjustment. Loosen hold down bolts and move strut to adjust. Scheme 1
Scheme 1: Camber and Caster adjustment. Loosen hold down bolts and move strut to adjust.
Toe adjustment. To adjust toe, move both bolts simultaneously. Scheme 2
Scheme 2: Toe adjustment. To adjust toe, move both bolts simultaneously.
Camber adjustment. To decrease camber, decrease width at eccentric contact point. Scheme 3
Scheme 3: Camber adjustment. To decrease camber, decrease width at eccentric contact point.
Toe adjustment. To decrease toe-in, move arm towards front of vehicle. Scheme 4
Scheme 4: Toe adjustment. To decrease toe-in, move arm towards front of vehicle.
| Application | Specification |
|---|
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 0 +/- 3/16 |
| Decimal | 0 +/- .18 |
| Caster in Degrees |
| Fraction | 6 1/16 +/- 3/16 |
| Decimal | 6.06 +/- .18 |
| Toe-In in Inches |
| Fraction | 1/8 +/- 1/32 |
| Decimal | .13 +/- .03 |
| Toe-In in Degrees |
| Fraction | 1/4 +/- 1/16 |
| Decimal | .25 +/- .06 |
| Toe-Out in Turns |
| Inner | 20° |
| Outer | 19 1/2° |
| Steering Axis Inclination (SAI) | (1) |
| Rear (Scheme 2) |
| Camber in Degrees |
| Fraction | 1 +/- 3/16 |
| Decimal | 1.0 +/- .18 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 1/16 +/- 1/16 |
| Decimal | .06 +/- .06 |
| Toe-In in Degrees |
| Fraction | 1/8 +/- 1/8 |
| Decimal | .13 +/- .13 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (911 CARRERA)
| Application | Specification |
|---|
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 0 +/- 3/16 |
| Decimal | 0 +/- .19 |
| Caster in Degrees |
| Fraction | 6 1/16 +/- 3/16 |
| Decimal | 6.06 +/- .18 |
| Toe-In in Inches |
| Fraction | 1/8 +/- 1/32 |
| Decimal | .13 +/- .03 |
| Toe-In in Degrees |
| Fraction | 1/4 +/- 1/16 |
| Decimal | .25 +/- .06 |
| Toe-Out in Turns |
| Inner | (1) |
| Outer | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Rear |
| Camber in Degrees |
| Fraction | 1/2 +/- 3/16 |
| Decimal | .5 +/- .18 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 3/32 +/- 3/32 |
| Decimal | .09 +/- .09 |
| Toe-In in Degrees |
| Fraction | 3/16 +/- 3/16 |
| Decimal | .19 +/- .19 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (911 TURBO)
| Application | Specification |
|---|
| Front |
| Camber in Degrees |
| Fraction | 1/2 +/- 3/16 |
| Decimal | .5 +/- .18 |
| Caster in Degrees |
| Fraction | 3 1/2 +/- 1/4 |
| Decimal | 3.5 +/- .25 |
| Toe-In in Inches |
| Fraction | 1/8 +/- 1/32 |
| Decimal | .13 +/- .03 |
| Toe-In in Degrees |
| Fraction | 1/4 +/- 1/16 |
| Decimal | .25 +/- .06 |
| Toe-Out in Turns |
| Inner | 20° |
| Outer | 18 11/16° |
| Steering Axis Inclination (SAI) | (1) |
| Rear |
| Camber in Degrees |
| Fraction | 11/16 +/- 3/16 |
| Decimal | .68 +/- .18 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 1/16 +/- 1/32 |
| Decimal | .06 +/- .03 |
| Toe-In in Degrees |
| Fraction | 1/8 +/- 1/16 |
| Decimal | .13 +/- .06 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (928S)
| Application | Specification |
|---|
| Front (Scheme 3) |
| Camber in Degrees |
| Fraction | 5/16 +/- 1/4 |
| Decimal | .31 +/- .25 |
| Caster in Degrees |
| Fraction | 2 1/2 +/- 1/2 |
| Decimal | 2.5 +/- .5 |
| Toe-In in Inches |
| Fraction | 1/16 +/- 1/32 |
| Decimal | .06 +/- .03 |
| Toe-In in Degrees |
| Fraction | 1/8 +/- 1/16 |
| Decimal | .13 +/- .06 |
| Toe-Out in Turns |
| Inner | 20° |
| Outer | 8 11/16° |
| Steering Axis Inclination (SAI) | (1) |
| Rear (Scheme 4) |
| Camber in Degrees |
| Fraction | 7/16 +/- 1/2 |
| Decimal | .43 +/- .5 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 0 +/- 1/16 |
| Decimal | 0 +/- .06 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/8 |
| Decimal | 0 +/- .13 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (944, 944 TURBO)
