Installing support for release handle
Installation Location
Note. In March 2005 Production introduced a technical modification to the release handle. The modification includes a new release handle support. For repair or interchangeability of the release handle, vehicles with an old release handle must also have a support fitted on the body.
Scheme 379
1. Partly loosen luggage-compartment lining -1-. see scheme 109
2. Position support for release handle -2- on the body and tighten with the fastening nut -3-. --> Tightening torque: 3 (2 ftlb.) Nm -0.5 (0.5 ftlb.) Nm see scheme 109
3. Fasten luggage compartment lining -1-. see scheme 109
Installation Location
Scheme 380
1. Connect electric plug connection -1- for microswitch. see scheme 111
Scheme 381
2. Press release handle -2- into luggage-compartment lining -3- and tighten with the fastening screw -1-. --> Tightening torque: 2.5 (2.0 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm see scheme 111, (Scheme 380).
3. Check inner release of luggage compartment (Trunk Entrapment). Refer to Checking inner release of luggage compartment (Trunk Entrapment) or Checking inner release of luggage compartment (Trunk Entrapment) .
