Notes
Note. Fill only with oil approved by Porsche. See Spare Parts Catalogue.
1. Raise the vehicle at the specified jacking points. Refer to 40 LIFTING THE VEHICLE - AS OF MY 2005 (ALL MODELS) .
2. Remove front underbody panel. Refer to 51 92 19 Removing and installing cover for front underbody - as of MY 2005 (All Models) .
3. Place oil collection pan under the transmission.
Scheme 97
1. Unscrew oil filler screw -A-. (Scheme 94)
| WARNING | Risk of scalding from hot oil |
> Let the oil cool down
> Wear personal protective gear (goggles, gloves)
The oil level is correct if transmission oil emerges. Continue with step 3.
If transmission oil does not flow out, the oil level in the final drive is too low. Continue with step 2.
2. Fill in transmission oil up to the bottom edge of the filler opening.
3. Clean oil filler plug and screw in with a new sealing ring.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Oil filler screw on front-axle final drive | Tightening torque | 28 (21 ftlb.) Nm |
1. Fit front underbody panel. Refer to 51 92 19 Removing and installing cover for front underbody - as of MY 2005 (All Models) .
2. Lower the vehicle.
| Designation | Type | Number | Explanation | |
|---|---|---|---|---|
| ATF filling device for filling transmission | Special tool | NR.161 |
Note. Fill only with oil approved by Porsche. See Spare Parts Catalogue. Hot vehicles should cool down before beginning the activity. Vehicle must be horizontal in order to be filled and checked.
1. Raise the vehicle at the prescribed jacking points. refer to 40 LIFTING THE VEHICLE - AS OF MY 2005 (ALL MODELS) .
2. Remove the underbody panels. Refer to 51 94 19 Removing and installing cover for rear underbody - as of MY 2005 (All Models) .
3. Place oil collection pan under the transmission.
