INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article for when you are familiar with adjustment procedure and only need a specification.
CAPACITIES
| Application | Amp Hr. Rating |
|---|---|
| 911 Carrera 2/4 | 72 |
BATTERY SPECIFICATIONS
| Application | Quantity | |
|---|---|---|
| Crankcase (Including Filter) | ||
| Oil Change Capacity | (1) 9.5 qts. (9.0L) | |
| Total Oil Capacity | (1) 12.2 qts. (11.5L) | |
| Automatic Transaxle (Dexron-II) | (2) 9.5 qts. (9.0L) | |
| Manual Transaxle (SAE 75 W 90) | ||
| 911 Carrera 2 | 3.8 qts. (3.6L) | |
| 911 Carrera 4 - Front Axle | 1.27 qts. (1.2L) | |
| 911 Carrera 4 - Rear Axle | 4.02 qts. (3.8L) | |
| (1) Check oil level with vehicle on level ground. Ensure engine is running at idle and normal operating temp. (2) Differential oil capacity is 1.9 pts. (0.9L) with Tiptronic automatic transaxle. Use SAE 75 W 90 oil. | ||
| (1) | Check oil level with vehicle on level ground. Ensure engine is running at idle and normal operating temp. |
| (2) | Differential oil capacity is 1.9 pts. (0.9L) with Tiptronic automatic transaxle. Use SAE 75 W 90 oil. |
FLUID CAPACITIES
SERVICE INTERVALS & SPECIFICATIONS
| Component | Interval (Miles) |
|---|---|
| Air Filter | 30,000 |
| Fuel Filter | 30,000 |
| Oil & Oil Filter | 15,000 |
| Spark Plugs | 30,000 |
| "V" Belt & Polyrib Belt | 30,000 |
REPLACEMENT INTERVALS
| Application | (1) Deflection In. (mm) |
|---|---|
| "V" Belt | 13/64-25/64 (5-10) |
| (1) With light pressure applied to center of belt. | |
| (1) | With light pressure applied to center of belt. |
BELT ADJUSTMENT
ENGINE COMPRESSION
Check engine compression with engine at normal operating temperature and specified cranking speed, all spark plugs removed (on dual plugs, remove exhaust side only), and throttle wide open.
| Application | Specification | |
|---|---|---|
| Compression Ratio | 11.3:1 | |
| Compression Pressure | ||
| Normal | 142-184 psi (10-13 kg/cm 2 ) | |
| Minimum | 107 psi (7.5 kg/cm 2 ) | |
| Maximum Variation Between Cylinders | 22 psi (1.5 kg/cm 2 ) | |
COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
Adjust valve clearance with engine cold. See VALVE CLEARANCE SPECIFICATIONS . Adjust valves in firing sequence: 1-6-2-4-3-5. Marks for TDC of each cylinder are located 120 degrees apart on crankshaft pulley.
| Application | In. (mm) |
|---|---|
| Intake & Exhaust (Cold) | .004 (.10) |
VALVE CLEARANCE SPECIFICATIONS
IGNITION COIL
| Application | Primary | Secondary |
|---|---|---|
| 911 Carrera 2/4 | .4-.6 | 5000-7200 |
IGN COIL RESISTANCE - Ohms@68°F (20°C)
HIGH TENSION WIRE RESISTANCE
| Application | Ohms |
|---|---|
| Plug Connectors | 3000 |
| Distributor Cap Connector | 1000 |
| (1) Cap and plug connector only. | |
| (1) | Cap and plug connector only. |
HIGH TENSION WIRE RESISTANCE (1)
SPARK PLUGS
| Application | Bosch No. |
|---|---|
| 911 Carrera 2/4 | FR 5 DTC |
SPARK PLUG TYPE
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|---|---|
| 911 Carrera 2/4 | .032 (.8) | (1) 22 (30) |
| (1) Clean and lubricate spark plug threads | ||
| (1) | Clean and lubricate spark plug threads |
SPARK PLUG SPECIFICATIONS
FIRING ORDER & TIMING MARKS
Note. For location of ignition timing mark, see ADJUSTMENTS article in the ENGINE PERFORMANCE Section
Firing Order & Distributor Rotation (Double Ignition System). Scheme 1
IGNITION TIMING
Ignition timing is controlled by DME engine management system and is not adjustable. Value given in IGNITION TIMING table is for verification purpose only.
| Application | Degrees @ RPM |
|---|---|
| 911 Carrera 2/4 | TDC +/- 3 @ 840-920 |
IGNITION TIMING
FUEL PUMP
Electric fuel pump is mounted inside fuel tank.
| Application | Pressure psi (kg/cm 2 ) | Volume in 30 Sec. Pts. (L) |
|---|---|---|
| 911 Carrera 2/4 | (1) 52-58 (3.6-4.0) | 1.8 (.85) |
| (1) Unregulated pressure (no vacuum applied to pressure regulator). Regulated pressure (vacuum applied to pressure regulator) is 45-51 psi (3.1-3.5 kg/cm 2 ). | ||
| (1) | Unregulated pressure (no vacuum applied to pressure regulator). Regulated pressure (vacuum applied to pressure regulator) is 45-51 psi (3.1-3.5 kg/cm 2 ). |
FUEL PUMP PERFORMANCE
INJECTOR RESISTANCE
| Application | Ohms |
|---|---|
| 911 Carrera 2/4 | 16 |
INJECTOR RESISTANCE
IDLE SPEED & MIXTURE
| Application | Idle RPM | CO Level |
|---|---|---|
| 911 Carrera 2/4 | 840-920 | (1) .4-1.2 % |
| (1) With oxygen sensor connected. Measurement is taken in front of catalytic converter. | ||
| (1) | With oxygen sensor connected. Measurement is taken in front of catalytic converter. |
IDLE SPEED & CO LEVEL
FAST IDLE SPEED
Fast idle speed is controlled by DME engine management system and is not adjustable.
Idle Speed Switch
See THROTTLE SWITCHES RESISTANCE . For additional information, see ADJUSTMENTS article in the ENGINE PERFORMANCE Section.
Full Throttle Switch
See THROTTLE SWITCHES RESISTANCE . For additional information, see ADJUSTMENTS article in the ENGINE PERFORMANCE Section.
Throttle Valve Potentiometer
See ADJUSTMENTS article in the ENGINE PERFORMANCE Section for adjustment information.
| Application | Ohms | |
|---|---|---|
| Idle Speed Switch (1) | ||
| Throttle Valve Closed | Less Than 10 | |
| Throttle Valve Open (2) | Infinite Resistance | |
| Full Throttle Switch (3) | ||
| Throttle Valve Closed | Infinite Resistance | |
| Throttle Valve Open (4) | Less Than 10 | |
| (1) Resistance is measured between terminals No. 1 and No. 2. (2) Throttle valve angle must be greater than one degree. (3) Resistance is measured between terminals No. 2 and No. 3. (4) Throttle valve must be at least 2/3 open. | ||
| (1) | Resistance is measured between terminals No. 1 and No. 2. |
| (2) | Throttle valve angle must be greater than one degree. |
| (3) | Resistance is measured between terminals No. 2 and No. 3. |
| (4) | Throttle valve must be at least 2/3 open. |
THROTTLE SWITCHES RESISTANCE
