Body control modules — Rear control unit circuit Porsche 718 Boxster 982

Components on these wiring diagrams 57

Click a component to highlight it on every diagram it appears on.

• Cl Button LED
• Coolant Level 1
• Dc O/P
• Defogger, Power Tops Systems
• Door Locks, Anti-Theft Systems
• Door Sill Lighting
• Enable Elv
• Exhaust Flap Control
• Extend Spoiler
• Front Lid Button
• Fuse 2
• Fuse 3
• Fuse 4
• Fuse 5
• Fuse 7
• Hall Sensor 1
• Hall Sensor 2
• Heated Rear Window Relay
• High Mounted Stop Light
• Hood Latch Closed
• Hood Sens 1
• Hood Sens 2
• Interior Lights, Exterior Lights Systems
• Latch Hook Unlocked Or Rear Window Breakage Sens Latch Hook Receiver
• Latching Hook Locked
• Left Reversing Light
• Left Taillight
• Lf Daytime Driving Light
• Lin 2 Lin 1
• Lr Fog Light
• Lr Lt Diagnosis
• Luggage Rack Light
• Number Plate Light +
• Ready To Latch
• Rear Eng/Luggage Comp Light
• Rear Lid Actuating Element
• Rear Lid Button
• Rear Lid Micro Sw
• Rear Window Wiper/Micro Sw Gnd
• Retract Spoiler
• Reversing Light Switch
• Rf Daytime Driving Lights
• Rh Reversing Light
• Right Taillight
• Rr Lt Diagnosis
• Sensor — Ground
• Stop Light Sw
• Term 15
• Term 30 1
• Term 30 4
• Term 30-2
• Term 30-3
• Term 31
• Trunk Entertainment Open
• Trunk Entrapment Closed
• Trunk Entrapment Operating Sw
• Wiper/Washer, Power Tops Systems
