Body control modules — Front controller circuit Porsche 718 Boxster S 982

Components on these wiring diagrams 72

Click a component to highlight it on every diagram it appears on.

• Anti-Lock Brakes, Instrument Cluster Systems
• Between The Seats - Pas Antenna
• Can Comfort High
• Can Comfort Low
• Crash Signal Input
• Door Locks, Anti-Theft Systems
• Eiss Illumination
• Enable Term 15
• Fl Prox Sens Sply
• Fl Term 31 Prox Sens
• Footwell Light
• Fr Prox Sens Sply
• Fr Term 31 Prox Sens
• Front Dual Washing Pump
• Front Lid Actuating Element
• Front Lid Micro Sw
• Frt Cntr Console- Pas Antenna
• Frt Lid Term 31 Prox Sens
• Frt Luggage Compt - Pas Antenna
• Fuse 1
• Fuse 2
• Fuse 6
• Fuse 7
• Glove Box Micro Sw
• Hazard Warning Light Button
• Headlight Washer
• Ignition Lock Sw 2
• Ignition Lock Sw 5
• Ignition Lock Sw 6
• Ignition Sw
• Lf Button, Close
• Lf Side Ind
• Lf Turn Signal
• Lh High Beam
• Lh Low Beam
• Lh Side Marker Light
• Light Sw Position 0
• Lin 1
• Lin 2
• Lin 3
• Lr Ind
• P/N Sw
• Rear Bumper Pas Antenna
• Rear Dual Washing Pump
• Relay Kl 15
• Relay Term 50
• Rf Button, Close
• Rf Low Beam
• Rf Side Ind
• Rf Turn Signal
• Rh High Beam
• Rh Side Marker Light
• Right End Of Dash
• Rl - Pas Antenna
• Rr - Pas Antenna
• Rr Dir Ind
• Rr Lid Prox Sens Sply
• Rr Lid Term 31 Prox Sens
• Sensor — Ground
• Sw 1 Ignition Lock
• Sw 3 Ignition Lock
• Sw 4 Ignition Lock
• Term 15 In Diagnosis
• Term 30 1
• Term 30-2
• Term 31
• Term 50-In Relay Diagnosis
• Terminal 15
• Trunk, Tailgate, Fuel Doors, Door Locks, Anti-Theft Systems
• Two-Tone Horns Relay
• Warning Light Button
• Washer Fluid Level
