Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Windshield Washer Solvent Container Bolt | 5.5 N.m | 49 lb in |
| Windshield Wiper Arm Nut | 20.5 N.m | 15 lb ft |
| Windshield Wiper Motor Bolts | 5.5 N.m | 48 lb in |
| Windshield Wiper Transmission Bolts | 5.5 N.m | 49 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Wiper/Washer System Schematics
Scheme 2
Scheme 3
Scheme 4
Scheme 4: Wiper/Washer System Component Views
| Callout | Component Name |
|---|
| 1 | Front Wiper Motor |
| 2 | Washer Fluid Reservoir |
| 3 | Wiper Switch |
| 4 | Wiper Fuse |
| 5 | Rear Wiper Motor |
| 6 | Rear Wiper Relay 2 |
| 7 | Rear Wiper Relay 1 |
