Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Front Seat Back Cushion Bolts | 43 N.m | 32 lb ft |
| Front Seat Mounting Bolts | 47 N.m | 35 lb ft |
| Rear Seat Back Center Pivot Support Bolt | 18 N.m | 13 lb ft |
| Rear Seat Back Center Pivot Support Mounting Bolts | 18 N.m | 13 lb ft |
| Rear Seat Back Cushion Lock Bolts | 18 N.m | 13 lb ft |
| Rear Seat Back Outer Pivot Support Bolt | 18 N.m | 13 lb ft |
| Rear Seat Back Lower Mounting Bolts | 41 N.m | 30 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Power Seat Systems Component Views
| Callout | Component Name |
|---|
| 1 | Passengers Seat Belt Warning Lamp |
| 2 | Passenger Seat Belt Warning Sensor |
| 3 | Passenger Inner Seat Belt Assembly |
| 4 | Driver Inner Seat Belt Assembly |
| 5 | Drivers Seat Belt Warning Lamp |
Scheme 2
| Callout | Component Name |
|---|
| 1 | Front Seat Belt Anchor Assembly |
| 2 | Front Outer Seat Belt Assembly |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Rear Seat Belt Assembly |
| 2 | Rear Center Seat Belt Retractor |
| 3 | Child Restraint Seat Anchor Bracket |
| 4 | Rear Inner Seat Belt Assembly |
| 5 | Child Restraint Seat Anchor Bracket |
