Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Inside Rearview Mirror Set Screw | 2 N.m | 18 lb in |
| Outside Rearview Mirror Nut | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Inside Rearview Mirror Schematics
Scheme 2
Scheme 2: Outside Rearview Mirror Schematics
Scheme 3
Scheme 3: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | RF Headlamp |
| 2 | Radiator |
| 3 | Ambient Air Temperature Sensor (DH3/DF5) |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Inside Rearview Mirror (ISRVM) |
| 2 | Hood |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Ambient Light Sensor |
| 2 | Instrument Panel Cluster (IPC) |
| 3 | Driver Information Center (DIC) Switch |
| 4 | Hazard Switch |
| 5 | Inflatable Restraint Passenger Air Bag ON/OFF Indicator |
| 6 | Rear Wiper/Washer Switch |
| 7 | Radio |
| 8 | HVAC Control Module |
| 9 | Heated Seat Switches |
| 10 | Power Window Switch - Main |
| 11 | Traction Control Switch |
| 12 | Dimmer Switch |
| 13 | Outside Rear View Mirror Switch |
Scheme 6
| Callout | Component Name |
|---|
| 1 | Outside Rearview Mirror - Driver |
| 2 | Window Motor - Driver |
| 3 | Door Lock Switch - Driver |
| 4 | Door Latch - Driver |
Scheme 7
| Callout | Component Name |
|---|
| 1 | Door Latch - Front Passenger |
| 2 | Door Lock Switch - Front Passenger |
| 3 | Window Motor - Front Passenger |
| 4 | Outside Rearview Mirror - Front Passenger |
Scheme 8
Scheme 8: Inside Rearview Mirror (ISRVM)
| Connector Part Information OEM: 917981-2 Service: 15306351 Description: 16-Way F 0.040/0.070 HYBRID I/O (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Inside Rearview Mirror (ISRVM) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1-7 | | | Not Used |
| 8 | BK | 850 | Ground |
| 9 | L-GN | 24 | Backup Lamp Supply Voltage |
| 10 | | | Not Used |
| 11 | D-GN/WH | 2514 | Keypad Signal |
| 12 | L-GN/BK | 2515 | Keypad Supply Voltage |
| 13 | YE | 643 | Accessory Voltage |
| 14 | YE/BK | 2516 | Keypad Green LED Signal |
| 15 | BN/WH | 2517 | Keypad Red LED Signal |
| 16 | | | Not Used |
Inside Rearview Mirror (ISRVM) Connector Terminal Identification
Scheme 9
Scheme 9: Outside Rearview Mirror - Driver
| Connector Part Information OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Outside Rearview Mirror - Driver Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | YE | 1499 | Driver Mirror Motor Left/Up Control |
| B | WH | 81 | Driver Mirror Motor Right Control |
| C | L-GN | 88 | Driver Mirror Motor Down Control |
Outside Rearview Mirror - Driver Connector Terminal Identification
