Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Condenser to Radiator Bolts | 9 N.m | 80 lb in |
| Coolant Heater | 50 N.m | 37 lb ft |
| Cooling Fan Motor Bolts | 6 N.m | 53 lb in |
| CRFM Bracket Bolts | 20 N.m | 15 lb ft |
| Fan Shroud to Radiator Bolts | 9 N.m | 80 lb in |
| Heater Inlet Pipe Nut | 25 N.m | 18 lb ft |
| Heater Outlet Pipe to Throttle Body Bolt | 10 N.m | 89 lb in |
| Heater Outlet Pipe to Throttle Body Nut | 10 N.m | 89 lb in |
| Heater Outlet Pipe to Upper Intake Manifold Nut | 25 N.m | 18 lb ft |
| Manifold Absolute Pressure (MAP) Sensor Bracket Bolt | 10 N.m | 89 lb in |
| Surge Tank to Body Bolts | 9 N.m | 80 lb in |
| Thermal Bypass Fitting Bolt | 12 N.m | 106 lb in |
| Thermal Bypass Pipe Bolt | 10 N.m | 89 lb in |
| Thermostat Housing Bolt | 25 N.m | 18 lb ft |
| Water Pump Bolt | 10 N.m | 89 lb in |
| Water Pump Pulley Bolt | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Wiring Schematics
Scheme 2
Scheme 2: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Inflatable Restraint Front End Sensor |
| 2 | Radiator Core Support |
| 3 | Cooling Fan - Right |
| 4 | Cooling Fan - Left |
Scheme 3
Scheme 3: Cooling Fan - Left
| Connector Part Information OEM: 13517352 Service: 88988506 Description: 2-Way F GT 280 Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15304720/19 Core/Insulation Crimp: 4/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Cooling Fan - Left Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | GY | 532 | Cooling Fan Motor Supply Voltage |
| A | GY | 532 | Cooling Fan Motor Supply Voltage |
| B | WH | 504 | Cooling Fan Low Reference |
| B | WH | 504 | Cooling Fan Low Reference |
Cooling Fan - Left Connector Terminal Identification
