Scheme 37
Scheme 37: Cigar Lighter/Power Outlet Schematics
Scheme 38
Scheme 38: Power Outlet Component Views
| Callout | Component Name |
|---|
| 1 | Auxiliary Power Outlet - Rear |
| 2 | Auxiliary Power Outlet - Front |
| 3 | Cigar Lighter |
Scheme 39
Scheme 39: Auxiliary Power Outlet - 1
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Auxiliary Power Outlet - 1 Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | RD/WH | 2540 | Battery Positive Voltage |
| B | BK | 650 | Ground |
Auxiliary Power Outlet - 1 Connector Terminal Identification
