Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Adjuster Plug Locknut | 68 N.m | 50 lb ft |
| Crossmember Support Bolts | 110 N.m | 71 lb ft |
| Inner Tie Rod | 100 N.m | 74 lb ft |
| O-Ring Union Fitting | 75 N.m | 55 lb ft |
| Power Steering Gear Mounting Bolts | 120 N.m | 89 lb ft |
| Power Steering Hose Fitting | 27 N.m | 20 lb ft |
| Power Steering Pressure Pipe Bracket Bolt | 26 N.m | 19 lb ft |
| Power Steering Pump Mounting Bolt (L61) | 26 N.m | 19 lb ft |
| Rack and Pinion Cylinder Line Fittings at Cylinder End | 27 N.m | 20 lb ft |
| Rack and Pinion Cylinder Line Fittings at Valve End | 17 N.m | 13 lb ft |
| Tie Rod Ball Stud Nut | 45 N.m | 33 lb ft |
| Tie Rod Jam Nut | 75 N.m | 55 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Power Steering System in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Important: Review the system description and operation in order to familiarize yourself with the system functions. Refer to Power Steering System Description and Operation .
