Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Backup Lamp Nuts | 2 N.m | 18 lb in |
| Fog Lamp Bolts | 6 N.m | 53 lb in |
| Fog Lamp Nuts | 2 N.m | 18 lb in |
| Headlamp Adjusters Mechanism Bolts | 6 N.m | 53 lb in |
| Headlamp Bolts | 4.5 N.m | 40 lb in |
| High Mounted Stop Lamp Screws | 2 N.m | 18 lb in |
| HVAC Control Screws | 2 N.m | 18 lb in |
| License Plate Lamp Screws | 2 N.m | 18 lb in |
| Lower I/P Trim Insulator Screw | 2.3 N.m | 20 lb in |
| Park Turn Lamp Screws | 2 N.m | 18 lb in |
| Side Marker Lamp Screws | 2 N.m | 18 lb in |
| Tail Lamp Nuts | 5 N.m | 44 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Begin the system diagnosis with the DIAGNOSTIC SYSTEM CHECK - LIGHTING SYSTEMS . The Diagnostic System Check will provide the following information
- The identification of the control module(s) which command the system
- The ability of the control module(s) to communicate through the serial data circuit
- The identification of any stored diagnostic trouble codes (DTCs) and their status
The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
