Body Control System: Removal & Installation Pontiac Sunfire I

Communication Devices 4 illustrations ~173 words

Removal Procedure

CAUTIONRefer to BATTERY DISCONNECT CAUTION in Cautions and Notices.

Scheme 48

Scheme 48

Scheme 49

Scheme 49
  1. Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
  2. Release the body control module (BCM) wire harness retainer from the BCM bracket.
  3. Disconnect the BCM electrical connectors from the BCM.
  4. Release the lock tabs and remove the BCM from the BCM bracket.
  5. Remove the BCM bracket nuts (2) if required.
  6. Remove the BCM bracket (1) as an assembly if required.

Scheme 50

Scheme 50: Installation Procedure

Scheme 51

Scheme 51
  1. Install the BCM bracket (1) as an assembly if required. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
  2. Install the BCM bracket nuts (2) if required. Tighten Tighten the nuts to 5 N.m (44 lb in).
  3. Install the BCM into the BCM bracket until lock tabs are fully seated.
  4. Connect the BCM electrical connectors to the BCM.
  5. Install the BCM wire harness retainer to the BCM bracket.
  6. Connect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE .
  7. Reprogram the BCM. Refer to «BODY CONTROL MODULE (BCM) PROGRAMMING/RPO CONFIGURATION»(ref-189110-S12843908592005090700000) .
