Fuses & Circuit Breakers Pontiac Sunbird II

Fuses & Circuit Breakers 3 illustrations ~492 words

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION (1983-90 MODELS)
Scheme 2: FUSE PANEL IDENTIFICATION (1983-90 MODELS)

Fuse & Circuit Breaker Identification

  1. 1 - 3 Amp Crank Sensor
  2. 2 - 35 Amp Power Accessories
  3. 3 - 10 Amp Radio, Antenna, Cruise Control
  4. 4 - 5 Amp Instrument Lights
  5. 5 - 35 Amp Power Windows
  6. 6 - 20 Amp Courtesy Lights, Cigarette Lighter
  7. 7 - 25 Amp Wiper
  8. 8 - 20 Amp Gauges, Chimes, Indicators, Defogger, Trunk Release
  9. 9 - 25 Amp Ventilation System
  10. 10 - 20 Amp Taillights
  11. 11 - 20 Amp Foglights
  12. 12 - 20 Amp Turn Signals, Back-Up Lights
  13. 13 - 20 Amp Choke Heater, Coolant Fan, Alternator
  14. 14 - 20 Amp Stoplights, Hazard Flashers
  15. 15 - 10 Amp ECM, Fuel Pump, Oil Pressure Light
  16. 16 - 15 Amp Computer Command Control Module

Scheme 3

Scheme 3: FUSE PANEL IDENTIFICATION (1991-93 MODELS)
Scheme 3: FUSE PANEL IDENTIFICATION (1991-93 MODELS)

Fuse & Circuit Breaker Identification

  1. 1 - 5 Amp Instrument Lights
  2. 2 - 10 Amp ECM, Fuel Injectors (1993)
  3. 3 - 15 Amp Cigarette Lighter, Glove Box Light (1993)
  4. Spare (1991)
  5. 4 - 10 Amp Radio Power
  6. 5 - 10 Amp Gauges, Audio Warning, Cluster Telltales, TCC, Rear Defogger Relay, Brake/Transaxle Shift Interlock (1993), Multi-Port Fuel Injection (1993)
  7. 6 - 15 Amp Parking Lights, Turn Lights
  8. 7 - 25 Amp HVAC, Heater & A/C Power, ABS, DRL Module (1993)
  9. 8 - 25 Amp Wiper
  10. 9 - 10 Amp Fuel Pump, Injectors
  11. 10 - 10 Amp Radio Memory, Digital Clock (1993)
  12. 11 - 20 Amp Interior Lights, Glove Box Light, Horn, Power Locks, Audible Warning (1993), Remote Liftgate Release (1993), Check Oil Light (1993)
  13. 12 - 30 Amp Power Window Breaker, DRL Breaker (Canada)
  14. 13 - 10 Amp Cruise Control
  15. 14 - 15 Amp Back-Up Lights, Turn Signal
  16. 15 - 20 Amp Stoplights, Hazard Flashers
  17. 16 - 20 Amp Flash-To-Pass (Not in Canada)
  18. 17 - 30 Amp (Circuit Breaker) Power Locks & Defogger Circuit Breaker
  19. 18 - 20 Amp (Circuit Breaker) Headlight Circuit Breaker

Scheme 4

Scheme 4: FUSE PANEL IDENTIFICATION (1994 MODELS)
Scheme 4: FUSE PANEL IDENTIFICATION (1994 MODELS)

Fuse & Circuit Breaker Identification

  1. 1 - 5 Amp Interior Lights Dimming
  2. 2 - 10 Amp ECM, Multiport Fuel Injection
  3. 3 - 10 Amp Automatic Door Unlock
  4. 4 - 15 Amp Cigarette Lighter, Interior Lights
  5. 5 - 10 Amp Radio/Audio Systems
  6. 6 - 10 Amp Gauges, Audio Warning, Brake/Transaxle Shift Interlock BTSI), HVAC, Instrument Panel, Multi-Port Fuel Injection, Rear Defogger
  7. 7 - 15 Amp Pk/Turn, Headlights
  8. 8 - 25 Amp ABS, Coolant Fan, HVAC, Headlights: Daytime Running Lights T61), Starter & Charging System
  9. 9 - 25 Amp Wiper/Washer
  10. 10 - 10 Amp Multiport Fuel Injection
  11. 11 - 10 Amp Radio/Audio Systems
  12. 12 - 15 Amp Audible Warning, Automatic Door Locks, Convertible Top, Horn, Instrument Panel, Interior Lights, Tailgate Release
  13. 13 - 30 Amp Convertible Top Power Windows
  14. 14 - 10 Amp Cruise Control
  15. 15 - 15 Amp Back-Up Lights, Exterior Lights
  16. 16 - 20 Amp Brake Transaxle Shift Interlock (BTSI), Exterior Lights: Stop/Hazard
  17. 17 - 20 Amp Headlights
  18. 18 - 30 Amp (Circuit Breaker) Automatic Door Locks, Rear Defogger
  19. 19 - 20 Amp (Circuit Breaker) Headlight, Headlights: Daytime Running Lights (T61)
