Fuse Block and Flasher Locations. Scheme 1
Scheme 1: Fuse Block and Flasher Locations
| Application | Location |
|---|
| Bonneville, Gran Prix & Parisienne |
| Fuse Block | (1) Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | On Fuse Block |
| Fiero |
| Fuse Block | (2) Near Parking Brake |
| Hazard Flasher | (7) Right of Glove Box |
| Turn Signal Flasher | (4) Left of Steering Column |
| Firebird & Trans Am |
| Fuse Block | (1) Near Parking Brake |
| Hazard Flasher | (5) Right of Steering Column |
| Turn Signal Flasher | (5) Right of Steering Column |
| Grand Am |
| Fuse Block | (1) Near Parking Brake |
| Hazard Flasher | Behind Center Console |
| Turn Signal Flasher | (4) Left of Steering Column |
| Sunbird |
| Fuse Block | (1) Near Parking Brake |
| Hazard Flasher | (2) Near Left Kick Panel |
| Turn Signal Flasher | (5) Right of Steering Column |
| 1000 |
| Fuse Block | (2) Near Parking Brake |
| Hazard Flasher | On Fuse Block |
| Turn Signal Flasher | (4) Left of Steering Column |
| 6000 & 6000 STE |
| Fuse Block | (5) In Glove Box |
| Hazard Flasher | (5) Behind Glove Box |
| Turn Signal Flasher | (5) Right of Steering Column |
| (1) Numbers refer to locations on Graphic. (Scheme 1) |
| (1) | Numbers refer to locations on Graphic. (Scheme 1) |
FUSE BLOCK & FLASHER LOCATIONS (1)
