Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Diagnostic Instructions

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

Circuit/System Description

When the fog lamp switch is placed in the ON position, ground is applied through the fog lamp switch signal circuit at G300 to the body control module (BCM). The BCM responds by applying battery voltage to the fog lamp relay control circuit to the coil side of the fog lamp relay. Battery voltage is applied at all times from the FOG LAMP fuse to the switch side of the fog lamp relay. When the relay coil is energized, the relay switch contacts close allowing battery voltage to be applied from the FOG LAMP fuse, through the relay switch contacts, to the fog lamps. Ground for the fog lamps is applied at all times at G101 for the left fog lamp and G102 for the right fog lamp. G102 also serves as ground for the coil side of the fog lamp relay.

Conditions for Running the DTC

Battery voltage must be between 9-16 volts.

B2530 02

This DTC will set when the BCM detects a short to ground in the front fog lamp relay control circuit.

B2530 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the front fog lamp relay control circuit.

Actions Taken When the DTC Sets

1. When DTC B2530 02 is present, the front fog lamps will not operate when the park lamps are ON and the front fog lamp switch is active.
2. When DTC B2530 05 is present, the front fog lamps and/or the front fog lamp indicator will be ON at all times or will not operate.

Conditions for Clearing the DTC

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Reference Information

Schematic Reference

Fog Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Testing

1. Ignition OFF, disconnect the front fog lamp relay.
2. Ignition OFF, scan tool OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal 85 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit terminal 86 and ground.
4. Command the Front Fog Lamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the front fog lamp relay.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The INT LIGHT fuse supplies battery voltage to the inadvertent load control relay located in the body control module (BCM). The BCM applies ground to the inadvertent relay control circuit which energizes the inadvertent load control relay coil. With the relay coil energized, the switch contacts close allowing battery voltage to flow from the INT LIGHT fuse to the inside rearview mirror lamps through the inside rearview mirror lamps supply voltage circuit. The inside rearview mirror lamps are controlled by a 3 position (OFF, DOOR, ON) switch. When the inside rearview mirror switch is placed in the DOOR position, the lamps are controlled by the BCM by grounding the courtesy lamp control circuit. When any door is opened, the jam switch contacts close and the BCM receives a door-open input. If the BCM receives a door lock or unlock input, the BCM will activate the inadvertent relay control circuit, providing battery voltage to the inside rearview mirror lamps. The BCM also provides ground to the inside rearview mirror lamps through the courtesy lamp control circuit.

Battery voltage must be between 9-16 volts.

Condition for Setting the DTC

DTC B2555 05 will set when the BCM detects a short to voltage or an open/high resistance in the courtesy lamp control circuit.

When DTC B2555 05 is present, the inside rearview mirror lamps will only operate manually with the inside rearview mirror lamp switches.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Schematic Reference

Interior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Interior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the inside rearview mirror.
2. Connect a test lamp between the appropriate control circuit terminal listed below and B+. Courtesy lamp control terminal 6 Courtesy lamp control terminal 1 - with UE1
3. Command the Courtesy Lamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or open/high resistance. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, test or replace the inside rearview mirror.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Inside Rearview Mirror Replacement»(/pontiac/solstice/i-final-2010-2010/remont/mirrors/#mirror-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

With the headlamp switch in the HEAD position, the headlamp switch headlamp ON signal circuit is grounded through the turn signal/multifunction switch at G300. In response to this input, the body control module (BCM) provides ground to either the headlamp low beam relay control circuit or the headlamp high beam relay control circuit. The position of the headlamp dimmer switch determines which relay coil has ground. The BCM supplies ground to the relay coil circuits, if the headlamps are necessary. The underhood fuse block supplies battery positive voltage to both relay switch circuits. When the low beam relay coil is energized, current flows through the LT LOW beam and the RT LOW beam fuses to the low beam headlamps. When the headlamp high beam relay coil is energized, current flows through the LT HI beam and the RT HI beam fuses to the high beam headlamps. Ground for the left headlamp assembly is provided at G101. Ground for the right headlamp assembly is provided at G102.

Battery voltage must be between 9-16 volts.

B2580 01

This DTC will set when the BCM detects a short to voltage in the headlamp high beam relay control circuit.

B2580 06

This DTC will set when the BCM detects a short to ground or an open/high resistance in the headlamp high beam relay control circuit.

When this DTC is present, the high beam headlamps will not operate.

When this DTC is present, the high beam headlamps will remain ON.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Schematic Reference

Headlights/Daytime Running Lights (DRL) Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the high beam relay.
2. Connect a test lamp between the B+ circuit terminal 85 and the relay control circuit terminal 86.
3. Command the High Beam Headlamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or open/high resistance. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, test or replace the high beam relay.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The body control module (BCM) receives an input from the instrument panel (I/P) dimmer switch. The BCM provides the I/P dimmer switch with voltage and a low reference. The I/P dimmer switch is a potentiometer that varies the input signal voltage to the BCM. This input determines the intensity level of the backlighting illumination. The driver may change intensity of the backlighting by positioning the I/P dimmer switch between the minimum and maximum settings. The BCM will default to full intensity if the input from the I/P dimmer switch is not within the specified values. The backlighting illumination intensity is controlled by the BCM by varying the pulse width modulation (PWM) voltage that feeds the dimming signal circuits of the individual lamps. All interior backlighting lamps are permanently grounded.

Battery voltage must be between 9-16 volts.

DTC B2625 02 will set when the BCM detects a short to ground in the instrument panel lamps supply voltage circuit.

Action Taken When the DTC Sets

When DTC B2625 02 is present, the interior backlighting will not operate.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Schematic Reference

Interior Lights Dimming Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Interior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connectors at all components fed by the I/P lamps control circuit.
2. Verify that DTC B2625 02 sets. If DTC B2625 02 sets, test the I/P lamps control circuit for a short to ground. If the circuit tests normal, replace the BCM.
3. Ignition OFF, connect each component fed by the I/P lamps control circuit one at a time and verify each time that the DTC does not set. If DTC B2625 02 sets as current, replace the component that caused the DTC to set.
4. If all circuits test normal, replace the BCM.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Electronic Traction Control Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/anti-locktraction-control/#antilock-brake-system-with-traction-control-system-stability-control-system)
2. «Front Side Door Window Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/heated-glassdefoggers/#fixed-and-moveable-windows-system)
3. «Radio Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) or «Radio Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)
4. «Instrument Cluster Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges) or «Instrument Cluster Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges)
5. «Fog Lamp Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
6. «Hazard Warning Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
7. «Heater and Air Conditioning Control Replacement»(/pontiac/solstice/i-final-2010-2010/remont/manual-hvac-system/#hvac-system-manual)
8. «Transmission Control Lever Knob Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-repair-instructions-on-vehicle) or «Transmission Control Lever Knob Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-repair-instructions-on-vehicle)
9. «Power Mirror Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/mirrors/#mirror-system)
10. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The ambient light sensor is used to monitor outside lighting conditions. The ambient light sensor provides a voltage signal that will vary between 2-4.9 volts depending on outside lighting conditions. The body control module (BCM) provides a low reference ground and a 5-volt reference signal to the ambient light sensor. The BCM monitors the ambient light sensor signal circuit to determine if outside lighting conditions are correct for either DRL or automatic lamp control (ALC) when the headlamp switch is in the AUTO position. In high outside light conditions the BCM will command the DRLs ON. In low light conditions, when the headlamps switch is in AUTO position, the BCM will command the low beam headlamps ON.

Battery voltage must be between 9-16 volts.

B2645 02

This DTC will set when the BCM detects a short to ground in the ambient light sensor signal circuit.

B2645 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the ambient light sensor signal circuit.

When DTC B2645 02 or B2645 05 is present, the ALC will default to ON.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the ambient light sensor.
2. Ignition OFF, scan tool OFF, doors CLOSED, test for less than 20 ohms between the low reference circuit terminal B and ground. If greater than the specified range, test the low reference circuit for an open/high resistance. If the circuit tests normal, replace the BCM.
3. Ignition ON, verify the scan tool ambient light sensor parameter is between 1-5 volts. If less than the specified range, test the signal circuit terminal A for a short to ground. If the circuit tests normal, replace the BCM. If greater than the specified range, test the signal circuit terminal A for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, replace the ambient light sensor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Ambient Light Sensor Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery positive voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps will not operate unless the ignition is in the ON position.

Battery voltage must be between 9-16 volts.

B3903 02

This DTC will set when the BCM detects a short to ground in the stop lamp switch signal circuit.

B3903 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the stop lamp switch signal circuit.

When DTC B3903 is present, the service vehicle soon indicator will illuminate.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the CHMSL.
2. Connect a test lamp between the signal circuit terminal A and ground.
3. Ignition ON, command the CHMSL ON and OFF by applying and releasing the brake pedal. The test lamp should turn ON and OFF as the brake pedal is applied and released. If the test lamp is always OFF, test the signal circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If the test lamp is always ON, test the signal circuit for a short to voltage. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, replace the CHMSL.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «High Mount Stop Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «High Mount Stop Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Ground is applied at all times at G300 to the turn signal/multifunction switch. The turn signal lamps may only be activated with the ignition switch in the ON or START position. When the turn signal/multifunction switch is placed in either the TURN RIGHT or TURN LEFT position, ground is applied to the body control module (BCM) through either the right turn or left turn signal switch signal circuit. The BCM then applies a pulsating voltage to the front and rear turn signal lamps through there respective voltage supply circuits. Ground for the left front turn signal lamp is supplied at G101. Ground for the right front turn signal lamp is supplied at G102. Ground for the left rear turn signal lamp is supplied at G400. Ground for the right rear turn signal lamp is supplied at G402.

Battery voltage must be between 9-16 volts.

B3948 02

This DTC will set when the BCM detects a short to ground in the LF turn signal voltage supply circuit.

B3948 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the LF turn signal voltage supply circuit.

B3949 02

This DTC will set when the BCM detects a short to ground in the RF turn signal voltage supply circuit.

B3949 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the RF turn signal voltage supply circuit.

When this DTC is present, the LF turn signal lamp will not operate.

When this DTC is present, the LF turn signal lamp will be ON at all times for a short to voltage condition. For an open condition, the LF turn signal lamp will be inoperative.

When this DTC is present, the RF turn signal lamp will not operate.

When this DTC is present, the RF turn signal lamp will be ON at all times for a short to voltage condition. For an open condition, the RF turn signal lamp will be inoperative.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Check the LF turn signal bulb. If the bulb is open, this DTC will set as current only.

Check the RF turn signal bulb. If the bulb is open, this DTC will set as current only.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the appropriate turn signal lamp.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal G and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit terminal A and ground.
4. Command the appropriate Turn Signal Lamp ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the appropriate turn signal lamp assembly.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Parking and Turn Signal Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__parking-and-turn-signal-lamp-replacement) or «Parking and Turn Signal Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Ground is applied at all times at G300 to the turn signal/multifunction switch. The turn signal lamps may only be activated with the ignition switch in the ON or START position. When the turn signal/multifunction switch is placed in either the TURN RIGHT or TURN LEFT position, ground is applied to the body control module (BCM) through either the right turn or left turn signal switch signal circuit. The BCM then applies a pulsating voltage to the front and rear turn signal lamps through there respective voltage supply circuits. Ground for the left front turn signal lamp is supplied at G101. Ground for the right front turn signal lamp is supplied at G102. Ground for the left rear turn signal lamp is supplied at G400. Ground for the right rear turn signal lamp is supplied at G402.

Battery voltage must be between 9-16 volts.

B3950 02

This DTC will set when the BCM detects a short to ground in the LR turn signal voltage supply circuit.

B3950 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the LR turn signal voltage supply circuit.

B3951 02

This DTC will set when the BCM detects a short to ground in the RR turn signal voltage supply circuit.

B3951 05

This DTC will set when the BCM detects a short to voltage or an open/high resistance in the RR turn signal voltage supply circuit.

When this DTC is present, the LR turn signal lamp will not operate.

When this DTC is present, the LR turn signal lamp will be ON at all times for a short to voltage condition. For an open condition, the LR turn signal lamp will be inoperative.

When this DTC is present, the RR turn signal lamp will not operate.

When this DTC is present, the RR turn signal lamp will be ON at all times for a short to voltage condition. For an open condition, the RR turn signal lamp will be inoperative.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 100 consecutive malfunction-free ignition cycles have occurred.

Check the LR turn signal bulb. If the bulb is open, this DTC will set as current only.

Check the RR turn signal bulb. If the bulb is open, this DTC will set as current only.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the appropriate turn signal lamp.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit terminal and ground.
4. Command the appropriate Turn Signal Lamp ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the appropriate turn signal lamp assembly.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Tail Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Convertible)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Sport Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery positive voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps will not operate unless the ignition is in the ON position.

Battery voltage must be between 9-16 volts.

C0277 06

This DTC will set when the BCM detects a short to ground or an open/high resistance in the brake pedal position sensor signal circuit for 0.5 seconds or greater.

C0277 07

This DTC will set when the BCM detects a short to battery voltage in the brake pedal position sensor signal or low reference circuits for 0.5 seconds or greater.

C0277 09

This DTC will set when the BCM detects the brake pedal position sensor signal is changing faster than possible under normal operating conditions.

1. The Service Vehicle Soon indicator is commanded ON.
2. When DTC C0277 is set as current, the vehicle will not start.
3. If the DTC sets while the vehicle is running, the BCM will activate the brake lights when the vehicles transmission is not in the PARK position and the vehicle is not accelerating.

Conditions for Clearing the MIL/DTC

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 50 malfunction-free ignition cycles have occurred.
3. A DTC will not clear the current status until the next ignition cycle.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the brake pedal position sensor.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the low reference circuit terminal C. If the test lamp does not illuminate, test the low reference circuit for an open/high resistance. If the circuit tests normal, replace the BCM.
3. Ignition ON, test for 4.8-5.2 volts between the 5-volt reference circuit terminal A and ground. If less than the specified range, test the 5-volt reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If greater than the specified range, test the 5-volt reference circuit for a short to voltage. If the circuit tests normal, replace the BCM.
4. Verify the scan tool BPP Sensor signal parameter is less than 0.2 volts. If greater than the specified range, test the signal circuit terminal B for a short to voltage. If the circuit tests normal, replace the BCM.
5. Install a 3A fused jumper wire between the signal circuit terminal B and the 5-volt reference circuit terminal A. Verify the scan tool BPP Sensor signal parameter is greater than 4.75 volts. If less than the specified range, test the signal circuit for short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
6. If all circuits test normal, test or replace the brake pedal position sensor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Brake Pedal Position Sensor Calibration»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-calibration)
2. «Brake Pedal Position Sensor Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-replacement)
3. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery positive voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps will not operate unless the ignition is in the ON position.

Battery voltage must be between 9-16 volts.

Conditions for Setting the DTC

DTC C0278 00 will set when the brake pedal position sensor home position is not learned.

1. The Service Vehicle Soon indicator is commanded ON.
2. When DTC C0278 is set as current, the vehicle will not start.
3. Stop lamps may not activate at the expected brake pedal positions.

1. A successful brake pedal position sensor calibration has been performed.
2. The condition responsible for setting the DTC no longer exists.
3. A history DTC will clear once 50 malfunction-free ignition cycles have occurred.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Verify the DTC sets under the Conditions for Running and Setting.
2. Perform the brake pedal position sensor recalibration procedure.
3. Operate the vehicle within the conditions that the customer experienced and verify the DTC does not reset. If the DTC resets, replace the brake pedal position sensor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Brake Pedal Position Sensor Calibration»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-calibration)
2. «Brake Pedal Position Sensor Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-replacement)

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery positive voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps will not operate unless the ignition is in the ON position.

Battery voltage must be between 9-16 volts.

C0870 03

This DTC will set when the BCM detects a short to ground in the brake pedal position sensor voltage reference circuit for 0.5 seconds or greater.

C0870 07

This DTC will set when the BCM detects a short to battery voltage in the brake pedal position sensor voltage reference circuits for 0.5 seconds or greater.

1. The Service Vehicle Soon indicator is commanded ON.
2. If the DTC sets while the vehicle is running, the BCM will activate the brake lights when the vehicles transmission is not in the PARK position and the vehicle is not accelerating.

1. The condition responsible for setting the DTC no longer exists.
2. A history DTC will clear once 50 malfunction-free ignition cycles have occurred.
3. A DTC will not clear the current status until the next ignition cycle.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the brake pedal position sensor.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the low reference circuit terminal C. If the test lamp does not illuminate, test the low reference circuit for an open/high resistance. If the circuit tests normal, replace the BCM.
3. Ignition ON, test for 4.8-5.2 volts between the 5-volt reference circuit terminal A and ground. If less than the specified range, test the 5-volt reference circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If greater than the specified range, test the 5-volt reference circuit for a short to voltage. If the circuit tests normal, replace the BCM.
4. If all circuits test normal, test or replace the brake pedal position sensor.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Brake Pedal Position Sensor Calibration»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-calibration)
2. «Brake Pedal Position Sensor Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__brake-pedal-position-sensor-replacement)
3. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

Symptoms - Lighting

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) before using a symptom table in order to verify that all of the following conditions are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system description and operation in order to familiarize yourself with the system functions. Refer to the following: «Exterior Lighting Systems Description and Operation»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) «Interior Lighting Systems Description and Operation»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the lighting system. Refer to «Checking Aftermarket Accessories»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Backup Lamps Malfunction (Automatic Transmission)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Backup Lamps Malfunction (Manual Transmission)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Courtesy Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Daytime Running Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
4. «Front Fog Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__front-fog-lamps-malfunction)
5. «Hazard Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
6. «Headlamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
7. «Interior Backlighting Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__interior-backlighting-malfunction)
8. «Park, License, and/or Tail Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
9. «Inside Rearview Mirror Lamp Inoperative»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
10. «Stop Lamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__stop-lamps-malfunction)
11. «Turn Signal Lamps and/or Indicators Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The underhood fuse block supplies battery positive voltage to the coil and switch terminals of the backup lamps relay. When the transmission is placed in the REVERSE position, the transmission control module (TCM) sends a serial data message to the body control module (BCM). The message indicates that the gear selector is in the REVERSE position. The BCM grounds the backup lamp relay control circuit which energizes the backup lamps relay. With the relay energized, the switch side contacts close and provide battery voltage to the backup lamps fuse through to the backup lamps. The backup lamps are permanently grounded at G402. With both power and ground the backup lamps illuminate. Once the driver moves the gear selector out of the REVERSE position, a message is sent by the TCM via serial data requesting the BCM to remove ground from the backup lamp relay control circuit. This opens the backup lamps relay switch contacts turning OFF the backup lamps.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the backup lamp relay.
2. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 87 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
3. Verify that a test lamp illuminates between the B+ circuit terminal 85 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ fuse is open, test the control circuit terminal 87 for a short to ground. If the circuit tests normal, test or replace the backup lamp relay.
4. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for an open/high resistance.
5. Disconnect the harness connector at the inoperative backup lamp.
6. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal G and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the inoperative backup lamp.
8. Connect a 10A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the backup lamps illuminate. If the backup lamps do not illuminate, test the control circuit for an open/high resistance. If the circuit tests normal, replace the inoperative backup lamp.
9. Connect a test lamp between the B+ circuit terminal 85 and the control circuit terminal 86.
10. Command the Backup Lamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
11. If all circuits test normal, test or replace the backup lamp relay.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
2. «Backup Lamp Bulb Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Backup Lamp Bulb Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Battery voltage is applied to the backup lamp switch when the ignition switch is in the RUN or CRANK positions. When the transmission is placed in the REVERSE position, the backup lamp switch provides battery voltage to the backup lamps. The backup lamps are permanently grounded at G402. With both power and ground the backup lamps illuminate. Once the driver moves the gear selector out of the REVERSE position, the backup lamp switch contacts open and the backup lamps turn OFF.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the inoperative backup lamp.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal G and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect the harness connector at the inoperative backup lamp.
4. Ignition OFF, disconnect the harness connector at the backup lamp switch.
5. Ignition ON, verify that a test lamp illuminates between the control circuit terminal A and ground. If the test lamp does not illuminate, test the control circuit for a short to ground or an open/high resistance.
6. Verify that a test lamp does not illuminate between the control circuit terminal B and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
7. Connect a 10-amp fused jumper between the control circuit terminal A and the control circuit terminal B. Verify the backup lamps illuminate. If the backup lamps do not illuminate, test the control circuit terminal B for a short to ground or an open/high resistance. If the circuit tests normal, test or replace the inoperative backup lamp.
8. If all circuits test normal, test or replace the backup lamp switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Backup Lamp Switch Replacement

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The INT LIGHT fuse supplies battery voltage to the inadvertent load control relay located in the body control module (BCM). The inadvertent load control relay is a non removable relay. The BCM applies ground to the inadvertent relay control circuit which energizes the inadvertent load control relay coil. With the relay coil energized, the switch contacts close allowing battery voltage to flow from the INT LIGHT fuse to the inside rearview mirror lamps through the inside rearview mirror lamps supply voltage circuit. The inside rearview mirror lamps are controlled by a 3 position (OFF, DOOR, ON) switch. When the inside rearview mirror switch is placed in the DOOR position, the lamps are controlled by the BCM by grounding the courtesy lamp control circuit. When any door is opened, the jam switch contacts close and the BCM receives a door-open input. If the BCM receives a door lock or unlock input, the BCM will activate the inadvertent relay control circuit, providing battery voltage to the inside rearview mirror lamps. The BCM also provides ground to the inside rearview mirror lamps through the courtesy lamp control circuit. When the BCM receives a rear hatch open input, the BCM will activate the rear compartment lamp control circuit to provide battery voltage to the rear compartment lamp. The rear compartment lamp is provided ground permanently at G402.

Schematic Reference

1. «Interior Lights Schematics»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Release Systems Schematics»(/pontiac/solstice/i-final-2010-2010/remont/door-locks-anti-theft-systems/#door-lock-systems-door-handles)

Connector End View Reference

Component Connector End Views

Description and Operation

Interior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

1. Observe the scan tool driver door ajar switch parameter located in Keyless Data while opening and closing the driver door. The reading should toggle between DOOR AJAR and DOOR CLOSED. If the reading does not change between the commanded states, refer to Door Ajar Switch Malfunction below.
2. Observe the scan tool door ajar switch parameter located in Keyless Data while opening and closing the passenger door. The reading should toggle between DOOR AJAR and DOOR CLOSED. If the reading does not change between the commanded states, refer to Door Ajar Switch Malfunction below.
3. Observe the scan tool trunk ajar switch parameter located in Keyless Data while opening and closing the rear compartment lid. The reading should toggle between TRUNK AJAR and TRUNK CLOSED. If the reading does not change between the commanded states, refer to Rear Compartment Lid Ajar Switch Malfunction below.

Door Ajar Switch Malfunction

1. Ignition OFF, disconnect the harness connector at the inoperative door lock actuator.
2. Ignition OFF, interior lamps OFF, doors CLOSED, test for less than 5.0 ohms between the appropriate ground circuit terminal listed below and ground. Door lock actuator - driver ground terminal 6 Door lock actuator - passenger ground terminal 3 If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool door ajar switch parameter is DOOR CLOSED. If the scan tool displays DOOR AJAR, test the appropriate signal circuit terminal listed below for a short to ground. If the circuit tests normal, replace the BCM. Left front door ajar switch signal terminal 4 Right front door ajar switch signal terminal 1
4. Install a 3A fused jumper wire between the appropriate signal circuit terminal listed below and ground. Verify the scan tool door ajar switch parameter is DOOR AJAR. Left front door ajar switch signal terminal 4 Right front door ajar switch signal terminal 1 If the scan tool displays DOOR CLOSED, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the inoperative door lock actuator.

Inside Rearview Mirror Courtesy Lamps Malfunction

1. Ignition OFF, disconnect the harness connector at the inside rearview mirror.
2. Ignition OFF, scan tool OFF, interior lamps OFF, test for less than 1.0 ohm between the appropriate ground circuit terminal listed below and ground. Inside rearview mirror ground terminal 6 Inside rearview mirror ground terminal 8 (UE1) If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition OFF, scan tool OFF, interior lamps OFF, test for less than 1.0 ohm between the appropriate control circuit terminal listed below and ground. Courtesy lamp control terminal 6 Courtesy lamp control terminal 1 (UE1) If greater than the specified range, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. Ignition ON, verify that a test lamp illuminates between the appropriate control circuit terminal listed below and ground. Inside rearview mirror lamps control terminal 7 Inside rearview mirror lamps control terminal 6 (UE1) If the test lamp does not illuminate, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, replace the inside rearview mirror.

Rear Compartment Lid Ajar Switch Malfunction

1. Ignition OFF, disconnect the harness connector at the rear compartment lid ajar switch.
2. Ignition OFF, exterior lamps OFF, test for less than 5.0 ohms between the ground circuit terminal B and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool trunk ajar switch parameter is TRUNK CLOSED. If the scan tool displays TRUNK AJAR, test the signal circuit terminal A for a short to ground. If the circuit tests normal, replace the BCM.
4. Install a 3A fused jumper wire between the signal circuit terminal A and ground. Verify the scan tool trunk ajar switch parameter is TRUNK AJAR. If the scan tool displays TRUNK CLOSED, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the rear compartment lid ajar switch.

Rear Compartment Courtesy Lamp Malfunction

1. Ignition OFF, disconnect the harness connector at the rear compartment lamp.
2. Open the rear compartment lid.
3. Ignition OFF, exterior lamps OFF, test for less than 5.0 ohms between the ground circuit terminal A and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
4. Ignition ON, verify that a test lamp illuminates between the control circuit terminal B and ground. If the test lamp does not illuminate, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, replace the rear compartment lamp.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Compartment Lid Release Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/door-locks-anti-theft-systems/#door-lock-systems-door-handles)
2. «Rear Compartment Courtesy Lamp Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Inside Rearview Mirror Replacement»(/pontiac/solstice/i-final-2010-2010/remont/mirrors/#mirror-system)
4. «Front Side Door Lock Replacement»(/pontiac/solstice/i-final-2010-2010/remont/door-locks-anti-theft-systems/#door-lock-systems-door-handles)
5. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The ambient light sensor is a light sensitive transistor that varies the voltage signal to the body control module (BCM) based on outside lighting conditions. When the ambient light sensor indicates daytime conditions, the body control module (BCM) grounds the DRL relay control circuit causing voltage to flow from the DRL fuse which energizes the DRL relay. With the DRL relay energized, the switch contacts close and voltage is applied to the left and right low beam headlamps. Any function or condition that turns on the headlamps will cancel DRL operation.

Schematic Reference

Headlights/Daytime Running Lights (DRL) Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, with a scan tool command the Headlamps On and OFF. The low beam headlamps should turn ON and OFF when changing between the commanded states. If the low beam headlamps do not turn ON and OFF when commanded, refer to «Headlamps Malfunction»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. Ignition ON, park brake released, verify with a scan tool the Park Brake Switch parameter displays Inactive. If not the specified value, refer to «Symptoms - Hydraulic Brakes»(/pontiac/solstice/i-final-2010-2010/remont/mechanical-hydraulic/#hydraulic-brake-system__symptoms-hydraulic-brakes) .

1. Ignition OFF, disconnect the DRL relay.
2. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 30 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
3. Verify that a test lamp illuminates between the B+ circuit terminal 86 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test the control circuit terminal 30 for a short to ground. If the circuit tests normal, test or replace the DRL relay.
4. Verify that a test lamp illuminates between the B+ circuit terminal 87 and ground. If the test lamp does not illuminate, test the B+ circuit for an open/high resistance.
5. Connect a test lamp between the B+ circuit terminal 86 and the control circuit terminal 85.
6. Command the DRL ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
7. If all circuits test normal, test or replace the DRL relay.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

When the fog lamp switch is placed in the ON position, ground is applied through the fog lamp switch signal circuit at G300 to the body control module (BCM). The BCM applies battery voltage through the fog lamp relay control circuit to the coil side of the fog lamp relay. Battery voltage is applied at all times from the FOG LAMP fuse to the switch side of the fog lamp relay. When the relay coil is energized, the relay switch contacts close and allow battery voltage to be applied from the FOG LAMP fuse, through the relay switch contacts, to the fog lamps. Ground for the fog lamps is applied at all times at G101 for the left fog lamp and G102 for the right fog lamp. G102 also serves as ground for the coil side of the fog lamp relay.

Schematic Reference

Fog Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Front Fog Lamp Switch parameter while pressing and releasing the front fog lamp switch. The parameter should change between Active and Inactive.

1. If the parameter does not change between the commanded states, refer to Fog Lamp Switch Malfunction below.
2. If the parameter changes between the commanded states, refer to Front Fog Lamps Malfunction below.

Fog Lamp Switch Malfunction

1. Ignition OFF, disconnect the harness connector at the fog lamp switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal A. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool Front Fog Lamp Switch parameter is Inactive. If not the specified value, test the signal circuit terminal C for a short to ground. If the circuit tests normal, replace the BCM.
4. Install a 3A fused jumper wire between the signal circuit terminal C and ground. Verify the scan tool Front Fog Lamp Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the fog lamp switch.

Front Fog Lamps Malfunction

1. Ignition OFF, disconnect the fog lamp relay.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal 85 and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition OFF, verify that a test lamp does not illuminate between the control circuit terminal 87 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
4. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test the control circuit terminal 87 for a short to ground.
5. Disconnect the harness connector at the Inoperative fog lamp.
6. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal B and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the inoperative fog lamp.
8. Connect a 15A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the fog lamps illuminate. If the fog lamps do not illuminate, test the control circuit for an open/high resistance. If the circuit tests normal, test or replace the inoperative fog lamp.
9. Connect a test lamp between the control circuit terminal 86 and ground.
10. Command the Fog Lamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or open/high resistance. If the circuit tests normal, replace the BCM.
11. If all circuits test normal, test or replace the fog lamp relay.

Front Fog Lamp Indicator Malfunction

Ignition ON, with a scan tool perform the Display Test for the instrument panel cluster (IPC) and observe the front fog lamp indicator.

1. If the front fog lamp indicator illuminates during the test, replace the BCM.
2. If the front fog lamp indicator does not illuminate during the test or remains illuminated at all times, replace the IPC.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Fog Lamp Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
3. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The hazard flashers may be activated in any power mode. The hazard switch is permanently grounded through G300. When the hazard switch is placed in the ON position, ground is applied through the hazard switch signal circuit to the body control module (BCM). The BCM supplies battery voltage to all 4 turn signal lamps in an ON and OFF duty cycle. When the hazard switch is placed in the ON position, the instrument panel cluster (IPC) receives a signal from the BCM via serial data requesting both turn signal indicators to be cycled ON and OFF.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the hazard switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal B. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool Hazard Lamp Switch parameter is Inactive. If not the specified value, test the signal circuit terminal C for a short to ground. If the circuit tests normal, replace the BCM.
4. Install a 3A fused jumper wire between the signal circuit terminal C and ground. Verify the scan tool Hazard Lamp Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the hazard switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Hazard Warning Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

With the headlamp switch in the HEAD position, the headlamp switch headlamp ON signal circuit is grounded through the turn signal/multifunction switch at G300. In response to this input, the body control module (BCM) provides ground to either the headlamp low beam relay control circuit through the headlamp switch signal circuit or the headlamp high beam relay control circuit. The position of the headlamp dimmer switch determines which relay coil has ground. The BCM supplies ground to the relay coil circuits, if the headlamps are necessary. The LO BEAM and HI BEAM relays are supplied with battery positive voltage at there coil and switch input circuits. When the low beam relay coil is energized, current flows through the LH LOW and the RH LOW fuses to the low beam headlamps. When the headlamp high beam relay coil is energized, current flows through the LH HIGH and the RH HIGH fuses to the high beam headlamps. The headlights may be switched to high beam with the movement of the headlamp dimmer switch lever. With the headlamp dimmer switch in the high beam position the BCM sends a message via serial data to the instrument panel cluster (IPC) requesting the IPC to illuminate the high beam indicator. Ground for the left headlamp assembly is provided at G101. Ground for the right headlamp assembly is provided at G102.

Schematic Reference

Headlights/Daytime Running Lights (DRL) Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, observe the scan tool headlamp off switch parameter while turning the headlamp switch ON and OFF. The parameter should change between Inactive and Active. If the parameter does not change between the commanded states, refer to Headlamp Switch Malfunction below.
2. Observe the scan tool flash to pass switch parameter while applying and releasing the flash to pass switch. The parameter should change between Inactive and Active. If the parameter does not change between the commanded states, refer to Headlamp Switch Malfunction below.
3. Observe the scan tool high beam select switch parameter while applying and releasing the high beam select switch. The parameter should change between Inactive and Active. If the parameter does not change between the commanded states, refer to Headlamp Switch Malfunction below.
4. Observe the scan tool headlamp on switch parameter while turning the headlamp switch ON and OFF. The parameter should change between Inactive and Active. If the parameter does not change between the commanded states, refer to Headlamp Switch Malfunction below.

Headlamp Switch Malfunction

1. Ignition OFF, disconnect the X1 and X2 harness connectors at the turn signal/multifunction switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal 1. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal B. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
4. Ignition ON, verify the scan tool Headlamp Off Switch parameter is Inactive. If not the specified value, test the signal circuit terminal 4 for a short to ground. If the circuit tests normal, replace the BCM.
5. Verify the scan tool Flash To Pass Switch parameter is Inactive. If not the specified value, test the signal circuit terminal C for a short to ground. If the circuit tests normal, replace the BCM.
6. Verify the scan tool High Beam Select Switch parameter is Inactive. If not the specified value, test the signal circuit terminal D for a short to ground. If the circuit tests normal, replace the BCM.
7. Verify the scan tool Headlamp On Switch parameter is Inactive. If not the specified value, test the signal circuit terminal 2 for a short to ground. If the circuit tests normal, replace the BCM.
8. Install a 3A fused jumper wire between the signal circuit terminal 4 and ground. Verify the scan tool Headlamp Off Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
9. Install a 3A fused jumper wire between the signal circuit terminal C and ground. Verify the scan tool Flash To Pass Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
10. Install a 3A fused jumper wire between the signal circuit terminal D and ground. Verify the scan tool High Beam Select Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
11. Install a 3A fused jumper wire between the signal circuit terminal 2 and ground. Verify the scan tool Headlamp On Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
12. If all circuits test normal, test or replace the turn signal/multifunction switch.

Headlamps Malfunction - Low Beam

1. Ignition OFF, disconnect the low beam relay.
2. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 87 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
3. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test the control circuit terminal 87 for a short to ground. If the circuit tests normal, test or replace the low beam relay.
4. Verify that a test lamp illuminates between the B+ circuit terminal 85 and ground. If the test lamp does not illuminate, test the B+ circuit for an open/high resistance.
5. Disconnect the harness connector at the inoperative low beam headlamp.
6. Ignition OFF, scan tool OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal B and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the inoperative low beam headlamp.
8. Connect a 20A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the low beam headlamps illuminate. If the low beam headlamps do not illuminate, test the control circuit for an open/high resistance. If the circuit tests normal, test or replace the inoperative low beam headlamp.
9. Connect a test lamp between the B+ circuit terminal 85 and the control circuit terminal 86.
10. Command the Low Beam Headlamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
11. If all circuits test normal, test or replace the low beam relay.

Headlamps Malfunction - High Beam

1. Ignition OFF, disconnect the high beam relay.
2. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 87 and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
3. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test the control circuit terminal 87 for a short to ground. If the circuit tests normal, test or replace the high beam relay.
4. Verify that a test lamp illuminates between the B+ circuit terminal 85 and ground. If the test lamp does not illuminate, test the B+ circuit for an open/high resistance.
5. Disconnect the harness connector at the inoperative high beam headlamp.
6. Ignition OFF, scan tool OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal B and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the inoperative high beam headlamp.
8. Connect a 20A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the high beam headlamps illuminate. If the high beam headlamps do not illuminate, test the control circuit for an open/high resistance. If the circuit tests normal, test or replace the inoperative high beam headlamp.
9. Connect a test lamp between the B+ circuit terminal 85 and control circuit terminal 86.
10. Command the High Beam Headlamps ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
11. If all circuits test normal, test or replace the high beam relay.

High Beam Indicator Malfunction

Ignition ON, with a scan tool perform the Display Test for the instrument panel cluster (IPC) and observe the high beam indicator.

1. If the high beam indicator illuminates during the test, replace the BCM.
2. If the high beam indicator does not illuminate during the test or remains illuminated at all times, replace the IPC.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Headlamp Bulb Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Headlamp Bulb Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
3. «Turn Signal Multifunction Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/steering-column-switches/#steering-wheel-steering-column)
4. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM or IPC replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The body control module (BCM) receives an input from the instrument panel (I/P) dimmer switch. The BCM provides the I/P dimmer switch with battery voltage and a low reference. The I/P dimmer switch is a potentiometer that varies the input signal voltage to the BCM. This input determines the intensity level of the backlighting illumination. The driver may change intensity of the backlighting by positioning the I/P dimmer switch between the minimum and maximum settings. The BCM will default to full intensity if the input from the I/P dimmer switch is not within the specified values. The backlighting illumination intensity is controlled by the BCM by varying the pulse width modulation (PWM) voltage that feeds the dimming signal circuits of the individual lamps. All interior backlighting lamps are permanently grounded.

Schematic Reference

Interior Lights Dimming Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Interior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool IP Dimmer Switch parameter while activating the switch from min to max. The voltage parameter should change as the switch is cycled between the min and max settings.

1. If the parameter does not change, refer to Dimmer Switch Malfunction below.
2. If the parameter changes, refer to Interior Backlighting Malfunction below.

Interior Backlighting Malfunction

1. Ignition ON, install a scan tool and observe the Interior Light Dimmed Command parameter while turning the parks lamps ON and OFF. The parameter should change between Off and On. If the parameter is always ON, test the control circuit terminal A7 X3 at the BCM for a short to voltage. If the circuit tests normal, replace the BCM. If the parameter is always OFF, test the control circuit terminal A7 X3 at the BCM for a short to ground or and open/high resistance. If the circuit tests normal, replace the BCM.
2. Ignition OFF, disconnect the harness connector at the component with the inoperative backlighting.
3. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
4. Connect a test lamp between the control circuit that supplies the inoperative component lamp and ground.
5. Command the park lamps ON and OFF with the park lamps switch. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM.
6. If all circuits test normal, test or replace the component with the inoperative backlighting.

Dimmer Switch Malfunction

1. Ignition OFF, disconnect the harness connector at the I/P dimmer switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the low reference circuit terminal B. If the test lamp does not illuminate, test the low reference circuit for an open/high resistance. If the circuit tests normal, replace the BCM.
3. Ignition ON, verify the scan tool I/P Dimmer Switch parameter is greater than 12 volts. If not the specified value, test the signal circuit terminal C for a short to ground. If the circuit tests normal, replace the BCM.
4. Install a 3A fused jumper wire between the signal circuit terminal C and the low reference circuit terminal B. Verify the scan tool I/P Dimmer Switch is less than 11 volts. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the IPC.
5. If all circuits test normal, test or replace the I/P dimmer switch.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Electronic Traction Control Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/anti-locktraction-control/#antilock-brake-system-with-traction-control-system-stability-control-system)
2. «Front Side Door Window Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/heated-glassdefoggers/#fixed-and-moveable-windows-system)
3. «Radio Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) or «Radio Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems)
4. «Instrument Cluster Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges) or «Instrument Cluster Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges)
5. «Fog Lamp Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
6. «Hazard Warning Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
7. «Instrument Panel Lamp Dimmer Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
8. «Heater and Air Conditioning Control Replacement»(/pontiac/solstice/i-final-2010-2010/remont/manual-hvac-system/#hvac-system-manual)
9. «Transmission Control Lever Knob Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-repair-instructions-on-vehicle) or «Transmission Control Lever Knob Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/automatic-trans/#automatic-transmission-5l40-e5l50-e-repair-instructions-on-vehicle)
10. «Power Mirror Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/mirrors/#mirror-system)
11. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Battery voltage is applied at all times to the coil and switch sides of the PRK LAMPS relay located in the underhood fuse block. Ground is applied at G300 to the turn signal/multifunction switch at all times. When the headlamp switch is placed in either the HEAD or PARK position, ground is applied to the park lamp switch signal circuit to the body control module (BCM). The BCM reacts to the signal from the park lamp switch by applying ground to the park lamp relay control circuit. This energizes the park lamp relay allowing voltage to flow from the PRK LAMPS fuse through the switch contacts of the relay to all park, tail, license, and side marker lamps. Ground for the front park and side marker lamps is supplied at G101 for the left and G102 for the right. Ground for the license and right rear tail lamps is supplied at G402, and the left rear tail lamps at G400.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Park Lamp Switch parameter while cycling the park lamp switch between the ON and OFF positions. The parameter should change between Active and Inactive.

1. If the parameters does not change between the commanded states, refer to Park Lamp Switch Malfunction below.
2. If the parameters change between the commanded states, refer to Park, License, Marker, and/or Tail Lamps Malfunction below.

Park Lamp Switch Malfunction

1. Ignition OFF, disconnect the X1 harness connector at the turn signal/multifunction switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal 1. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool Park Lamp Switch parameter is Inactive. If not the specified value, test the signal circuit terminal 3 for a short to ground. If the circuit tests normal, replace the BCM.
4. Install a 3A fused jumper wire between the signal circuit terminal 3 and ground. Verify the scan tool Park Lamp Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the turn signal/multifunction switch.

Park, License, Marker, and/or Tail Lamps Malfunction

1. Ignition OFF, disconnect the park lamp relay.
2. Ignition ON, verify that a test lamp does not illuminate between the control circuit terminal 87and ground. If the test lamp illuminates, test the control circuit for a short to voltage.
3. Verify that a test lamp illuminates between the B+ circuit terminal 30 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test the control circuit terminal 87 for a short to ground. If the circuit tests normal, test or replace the park lamp relay.
4. Verify that a test lamp illuminates between the B+ circuit terminal 85 and ground. If the test lamp does not illuminate, test the B+ circuit for an open/high resistance.
5. Disconnect the harness connector at the inoperative park or license lamp.
6. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the inoperative park lamp ground circuit and ground If greater than the specified range, test the ground circuit for an open/high resistance.
7. Connect the harness connector at the inoperative park or license lamp.
8. Connect a 15A fused jumper wire between the B+ circuit terminal 30 and the control circuit terminal 87. Verify the park lamps illuminate. If the park lamps do not illuminate, test the control circuit for an open/high resistance. If the circuit tests normal, test or replace the inoperative park lamp.
9. Connect a test lamp between the B+ circuit terminal 85 and the control circuit terminal 86.
10. Command the Parks Lamps On and Off with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to ground. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
11. If all circuits test normal, test or replace the park lamp relay.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Parking and Turn Signal Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__parking-and-turn-signal-lamp-replacement) or «Parking and Turn Signal Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Tail Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Convertible)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Sport Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Front Side Marker Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
4. «Rear License Plate Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Rear License Plate Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
5. «Relay Replacement (Attached to Wire Harness)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions) or «Relay Replacement (Within an Electrical Center)»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-repair-instructions)
6. «Turn Signal Multifunction Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/steering-column-switches/#steering-wheel-steering-column)
7. «Front Side Marker Lamp Bulb Replacement»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
8. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The INT LIGHT fuse supplies battery voltage to the inadvertent load control relay located in the body control module (BCM). The BCM applies ground to the inadvertent relay control circuit which energizes the inadvertent load control relay coil. With the relay coil energized, the switch contacts close allowing battery voltage to flow from the INT LIGHT fuse to the inside rearview mirror lamps through the inside rearview mirror lamps supply voltage circuit. The inside rearview mirror lamps are controlled by a 3 position (OFF, DOOR, ON) switch. When the inside rearview mirror switch is placed in the DOOR position, the lamps are controlled by the BCM by grounding the courtesy lamp control circuit. When any door is opened, the jam switch contacts close and the BCM receives a door-open input. If the BCM receives a door lock or unlock input, the BCM will activate the inadvertent relay control circuit, providing battery voltage to the inside rearview mirror lamps. The BCM also provides ground to the inside rearview mirror lamps through the courtesy lamp control circuit.

Schematic Reference

Interior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Interior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, disconnect the harness connector at the inside rearview mirror.
2. Ignition OFF, scan tool OFF, interior lamps OFF, test for less than 1 ohm between the appropriate ground circuit terminal listed below and ground. Inside rearview mirror ground terminal 6 Inside rearview mirror ground terminal 8 - with UE1 If greater than the specified range, test the ground circuit for an open/high resistance.
3. Ignition OFF, scan tool OFF, interior lamps OFF, test for less than 1 ohm between the appropriate control circuit terminal listed below and ground. Courtesy lamp control terminal 6 Courtesy lamp control terminal 1 - with UE1 If greater than the specified range, test the control circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
4. Ignition ON, verify that a test lamp illuminates between the appropriate control circuit terminal listed below and ground. Inside rearview mirror lamps control terminal 7 Inside rearview mirror lamps control terminal 6 - with UE1 If the test lamp does not illuminate, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, replace the inside rearview mirror.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Inside Rearview Mirror Replacement»(/pontiac/solstice/i-final-2010-2010/remont/mirrors/#mirror-system)
2. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps will not operate unless the ignition is in the ON position. Ground for the left rear stop lamps is provided at G400. Ground for the right rear stop lamps is provided by G402.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Stop Lamps Malfunction

1. Ignition OFF, disconnect harness connector at the inoperative stop lamp.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit and ground.
4. Command the inoperative Stop Lamp On and Off with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, replace the inoperative stop lamp.

High Mounted Stop Lamp Malfunction

1. Ignition OFF, disconnect the harness connector at the CHMSL.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit terminal B and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the signal circuit terminal A and ground.
4. Ignition ON, command the CHMSL ON and OFF by applying and releasing the brake pedal. The test lamp should turn ON and OFF as the brake pedal is applied and released. If the test lamp is always OFF, test the signal circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM. If the test lamp is always ON, test the signal circuit for a short to voltage. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, replace the CHMSL.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «High Mount Stop Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «High Mount Stop Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Tail Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Convertible)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Sport Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Tail Lamp Bulb Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Bulb Replacement (Solstice GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
4. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM replacement, setup, and programming

1. Perform the «Diagnostic System Check - Vehicle»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
2. Review «Strategy Based Diagnosis»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
3. «Diagnostic Procedure Instructions»(/pontiac/solstice/i-final-2010-2010/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Ground is applied at all times at G300 to the turn signal/multifunction switch. The turn signal lamps may only be activated with the ignition switch in the ON or START position. When the turn signal/multifunction switch is placed in either the TURN RIGHT or TURN LEFT position, ground is applied to the body control module (BCM) through either the right turn or left turn signal switch signal circuit. Battery voltage is applied at all times from the BATT MAIN 3 fuse to the BCM. The BCM then applies a pulsating voltage to the front and rear turn signal lamps. Ground for the left front turn signal lamp is supplied at G101. Ground for the right front turn signal lamp is supplied at G102. Ground for the left rear turn signal lamp is supplied at G400. Ground for the right rear turn signal lamp is supplied at G402.

Schematic Reference

Exterior Lights Schematics

Connector End View Reference

Component Connector End Views

Description and Operation

Exterior Lighting Systems Description and Operation

Electrical Information Reference

1. «Circuit Testing»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
2. «Connector Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
3. «Testing for Intermittent Conditions and Poor Connections»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures)
4. «Wiring Repairs»(/pontiac/solstice/i-final-2010-2010/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Right and Left Turn Signal Switch parameters while cycling the turn signal switch between the left and right positions. The parameters should change between Active and Inactive.

1. If the parameters do not change between the commanded states, refer to Turn Signal Switch Malfunction below.
2. If the parameters change between the commanded states and the turn signal indicators are inoperative, refer to Turn Signal Lamps Malfunction below.

Turn Signal Switch Malfunction

1. Ignition OFF, disconnect the X2 harness connector at the turn signal/multifunction switch.
2. Ignition OFF, verify that a test lamp illuminates between B+ and the ground circuit terminal B. If the test lamp does not illuminate, test the ground circuit for an open/high resistance.
3. Ignition ON, verify the scan tool Left Turn Signal Switch parameter is Inactive. If not the specified value, test the signal circuit terminal G for a short to ground. If the circuit tests normal, replace the BCM.
4. Verify the scan tool Right Turn Signal Switch parameter is Inactive. If not the specified value, test the signal circuit terminal H for a short to ground. If the circuit tests normal, replace the BCM.
5. Install a 3A fused jumper wire between the signal circuit terminal G and ground. Verify the scan tool Left Turn Signal Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
6. Install a 3A fused jumper wire between the signal circuit terminal H and ground. Verify the scan tool Right Turn Signal Switch parameter is Active. If not the specified value, test the signal circuit for a short to voltage or an open/high resistance. If the circuit tests normal, replace the BCM.
7. If all circuits test normal, test or replace the turn signal/multifunction switch.

Turn Signal Lamps Malfunction

1. Ignition OFF, disconnect the harness connector at the inoperative turn signal lamp.
2. Ignition OFF, exterior lamps OFF, test for less than 5 ohms between the ground circuit and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
3. Connect a test lamp between the control circuit and the ground circuit.
4. Command the appropriate Turn Signal Lamp ON and OFF with a scan tool. The test lamp should turn ON and OFF when changing between the commanded states. If the test lamp is always ON, test the control circuit for a short to voltage. If the circuit tests normal, replace the BCM. If the test lamp is always OFF, test the control circuit for a short to ground or an open/high resistance. If the circuit tests normal, replace the BCM.
5. If all circuits test normal, test or replace the appropriate turn signal lamp assembly.

Turn Signal Indicators Malfunction

Ignition ON, with a scan tool perform the Display Test for the instrument panel cluster (IPC) and observe the turn signal lamp indicators.

1. If the turn signal lamp indicators illuminate during the test, replace the BCM.
2. If the turn signal lamp indicators do not illuminate during the test or remain illuminated at all times, replace the IPC.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Parking and Turn Signal Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__parking-and-turn-signal-lamp-replacement) or «Parking and Turn Signal Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
2. «Tail Lamp Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Convertible)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (Sport Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Replacement (GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
3. «Parking and Turn Signal Lamp Bulb Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system__parking-and-turn-signal-lamp-bulb) or «Parking and Turn Signal Lamp Bulb Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
4. «Tail Lamp Bulb Replacement (SKY)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) or «Tail Lamp Bulb Replacement (Solstice GXP Coupe)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system)
5. «Turn Signal Multifunction Switch Replacement»(/pontiac/solstice/i-final-2010-2010/remont/steering-column-switches/#steering-wheel-steering-column)
6. «Control Module References»(/pontiac/solstice/i-final-2010-2010/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for BCM or IPC replacement, setup, and programming

Brake Pedal Position Sensor Calibration

Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.

Calibration Criteria

Brake pedal position sensor calibration must be performed after the brake pedal position sensor or body control module (BCM) have been serviced. The calibration procedure will set brake pedal position sensor home value. This value is used by the BCM to determine the action of the driver applying the brake system and to provide this information to the vehicle subsystems via the GMLAN communication bus.

Calibration Procedure

1. Apply the parking brake.
2. Place the transmission in the PARK position for automatic transmission or NEUTRAL for manual transmission.
3. Install a scan tool.
4. Clear all BCM DTCs before proceeding.
5. Turn ON the ignition, with the engine OFF.
6. Navigate to the BCM menu.
7. Select Module Setup menu item.
8. Select BPP Sensor Calibration procedure and follow the directions displayed on the screen.

Brake Pedal Position Sensor Replacement

Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Headlamp Aiming (SKY)

The vehicle has a visual optical headlamp aiming system. The aim has been preset at the factory and should need no further adjustment

However, If the vehicle is damaged in an accident, the headlamp aim may be affected and adjustment may be necessary.

If oncoming vehicles flash their high beams at you, this may also mean the vertical aim needs to be adjusted.

It is recommended that the vehicle is taken to your dealer for service if the headlamps need to be re-aimed. It is possible however, to re-aim the headlamps as described in the following procedure.

The vehicle should be properly prepared as follows

1. The vehicle should be placed so the headlamps are 25 ft (7.6 m) from a light colored wall or other flat surface.
2. The vehicle must have all four tires on a perfectly level surface which is level all the way to the wall or other flat surface.
3. The vehicle should be placed so it is perpendicular to the wall or other flat surface.
4. The vehicle should not have any snow, ice or mud on it.
5. The vehicle should be fully assembled and all other work stopped while headlamp aiming is being done.
6. The vehicle should be normally loaded with a full tank of fuel and one person or 160 lbs (75 kg) on the driver seat.
7. Tires should be properly inflated.

Headlamp aiming is done with the vehicle low-beam headlamps. The high-beam headlamps will be correctly aimed if the low-beam headlamps are aimed properly.

1. The vertical headlamp aiming screw (1) is located behind the front marker lamp. Refer to «Front Side Marker Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) for lamp removal and adjuster screw access.
2. The adjustment screw can be turned with a standard No. 2 phillips driver.
3. To adjust the vertical aim on the headlamps, close the hood, and complete the following
4. Find the aim dots on the lens of the lamp assembly.
5. Measure the distance from the ground to the aim dot on the lamp with the hood in the closed position. Record the distance.
6. At the wall or other flat surface, measure from the ground upward the recorded distance and draw or tape a horizontal line the width of the vehicle.
7. Turn on the low-beam headlamps and place a piece of cardboard or equivalent in front of the headlamp not being aimed. This should allow only the beam of light from the headlamp being aimed to be seen on the flat surface.
8. Turn the vertical aiming screw until the headlamp beam is aimed to the horizontal tape line. The top edge of the cut-off should be positioned at the bottom edge of the horizontal tape line.
9. Repeat steps 5 and 6 for the opposite headlamp.

Headlamp Aiming (Solstice)

The vehicle has a visual optical headlamp aiming system. The aim has been preset at the factory and should need no further adjustment

However, If the vehicle is damaged in an accident, the headlamp aim may be affected and adjustment may be necessary.

The vehicle should be properly prepared as follows

1. Inspect the alignment and adjustment of the hood.
2. The vehicle should be placed so the headlamps are 25 ft (7.6 m) from a light colored wall or other flat surface.
3. The vehicle must have all four tires on a perfectly level surface which is level all the way to the wall or other flat surface.
4. The vehicle should be placed so it is perpendicular to the wall or other flat surface.
5. The vehicle should not have any snow, ice or mud on it.
6. The vehicle should be fully assembled and all other work stopped while headlamp aiming is being done.
7. The vehicle should be normally loaded with a full tank of fuel and one person or 160 lbs (75 kg) on the driver seat.
8. Tires should be properly inflated.
9. The hood should be checked for proper adjustment. Refer to «Hood Adjustment»(/pontiac/solstice/i-final-2010-2010/remont/exterior-body-panels/#bolted-exterior-body-panels-closures__hood-adjustment) .
10. The hood should be in the closed position.

Headlamp aiming is done with the vehicle low-beam headlamps. The high-beam headlamps will be correctly aimed if the low-beam headlamps are aimed properly.

1. The vertical headlamp aiming screw (1) is located behind the front marker lamp. Refer to «Front Side Marker Lamp Replacement (Solstice)»(/pontiac/solstice/i-final-2010-2010/remont/exterior-lights/#lighting-system) for lamp removal and adjuster screw access.
2. The adjustment screw can be turned with a standard No. 2 Phillips driver.
3. To adjust the vertical aim on the headlamps, close the hood, and do the following
4. Find the aim dots (1) on the lens of the lamp assembly.
5. Measure the distance from the ground to the aim dot on the lamp with the hood in the closed position. Record the distance.
6. At the wall or other flat surface, measure from the ground upward the recorded distance and draw or tape a horizontal line the width of the vehicle.
7. Turn on the low-beam headlamps and place a piece of cardboard or equivalent in front of the headlamp not being aimed. This should allow only the beam of light from the headlamp being aimed to be seen on the flat surface.
8. Turn the vertical aiming screw until the Right Gradient Line (Cutoff Line) (2) is set at the H-H (Horizontal Axis) (1) within +/- 2.0 inches measured at 25 feet.
9. Repeat steps 7 and 8 for the opposite headlamp.

Scheme 21

Scheme 22

Adjustment Procedure

Proper road illumination and safety require the fog lamps to be aimed. The front fog lamp aim should be checked when a new front fog lamp assembly is installed, or if any service repairs have been performed to the vehicle which disturb the front fog lamp mounting or the vehicle ride height.

There are no horizontal adjustments for aiming the front fog lamp assemblies on this vehicle.

1. To ensure accurate vertical front fog lamp aiming, first perform the following steps to prepare the vehicle.
2. Make sure that all the components are in place on the vehicle, the tires are properly inflated, and there is not any mud or snow clinging to the vehicle.
3. Stop all other operations of work on the vehicle.
4. Make sure the fuel level is 1/2 full or more.
5. Jounce the vehicle to settle the suspension.
6. Place the vehicle on a level surface 7.6 m (25 ft) from the target screen.
7. Measure the distance from the floor to the center of the fog lamp (5).
8. Using this measurement, mark the horizontal centerline of the fog lamp (1) on the target screen directly in front of the vehicle.
9. Start the vehicle in order to level the suspension.
10. Turn the front fog lamps ON.
11. Open the hood and reach in behind the directional lamp housing in order to adjust the fog lamp vertical adjuster screw.
12. Adjust the fog lamp up or down until the top edge of the high intensity zone on the screen is 102 mm (4 in) below the horizontal centerline (1).
13. Turn OFF the front fog lamps.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Parking and Turn Signal Lamp Replacement (SKY)

Scheme 27

Parking and Turn Signal Lamp Bulb Replacement (SKY)

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Rear License Plate Lamp Bulb Replacement (Solstice)

Rear License Plate Lamp Bulb Replacement (SKY)

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Exterior Lamps

The exterior lighting consist of the following lamps

1. Headlamps
2. Daytime running lamps (DRL)
3. Fog lamps
4. Park, tail, license and marker lamps
5. Turn signal lamps
6. Hazard warning lamps
7. Stop lamps
8. Backup lamps

Headlamps

The headlamps consist of 2 interchangeable single filament bulbs or 2 high intensity discharge (HID) arc tubes and ballast on each side of the vehicle which provide high and low beams. The lower bulb in the headlamp is the high beam and the upper bulb is the low beam.

The headlamps may be turned ON in two different ways

1. When the headlamp switch is placed in the ON position, for normal operation
2. When the headlamp switch is placed in the AUTO position, for automatic lamp control (ALC)

With the headlamp switch in the ON position, the headlamp switch headlamp ON signal circuit is grounded through the turn signal/multifunction switch. In response to this input, the body control module (BCM) provides ground to either the headlamp low beam relay control circuit or the headlamp high beam relay control circuit. The position of the headlamp dimmer switch determines which relay coil has ground. The BCM supplies ground to the relay coil circuits, if the headlamps are necessary. The underhood fuse block supplies battery positive voltage to both relay switch circuits. When the low beam relay coil is energized, current flows through the LT LOW BEAM and the RT LOW BEAM fuses to the low beam headlamps. When the headlamp high beam relay coil is energized, current flows through the LT HI BEAM and the RT HI BEAM fuses to the high beam headlamps. When the headlamp dimmer switch lever is pulled toward the driver, the flash to pass (FTP) switch closes. This grounds the BCM flash to pass switch signal. In response to this input, the BCM energizes the high beam relay. Both high beams will remain ON until the driver releases the headlamp dimmer switch handle. If the low beam headlamps were ON during FTP operation, the low beams remain ON. The headlights may be switched to high beam with the opposite movement of the headlamp dimmer switch lever. With the headlamp dimmer switch in the high beam position the BCM sends a serial data message to the instrument panel cluster (IPC) requesting the IPC to illuminate the high beam indicator. If the headlamp switch is left in the ON position, the inadvertent power control feature will turn OFF the headlights 10 minutes after the ignition switch is turned to the OFF position. If the driver places the headlight switch in the ON position after the ignition switch has been turned OFF, or if the ignition switch is in the ACCY position, the headlights will remain ON until turned OFF or the battery runs dead.

Automatic Lamp Control/Twilight Sentinel

Place the turn signal/multifunction switch in the OFF position for automatic lamp control. During automatic lamp control the headlamps will be off during daylight conditions but will turn on when the ambient light sensor detects low outside light level. The ambient light sensor is a light sensitive transistor that varies the voltage signal to the body control module (BCM). The BCM applies ground to the headlamp low beam relay control circuit which energizes the low beam relay, closing the switched side and applies battery voltage to the LEFT and RIGHT LOW BEAM fuses. Battery voltage is applied from the low beam fuses, through the low beam voltage supply circuits to the headlamp assembly.

Flash to Pass (FTP)

When the low beam headlamps are on and the turn signal/multifunction switch is momentarily placed in the flash to pass (FTP) position, ground is applied to the turn signal/multifunction switch. The turn signal/multifunction switch applies ground to the body control module (BCM) through the FTP switch signal circuit. The BCM then applies ground to the high beam relay control circuit. This energizes the high beam relay, closing the switched side of the high beam relay, applying battery voltage to the LEFT and RIGHT HIGH BEAM fuses. Battery voltage is applied from the High Beam fuses through the high beam solenoid switched voltage supply circuit to the high beam solenoid assembly inside of the headlamp. This causes the solenoid to retract a plate partially covering the low beam headlamps and allowing the lamps to illuminate at full brightness momentarily.

Daytime Running Lamps (DRL)

The daytime running lamps (DRL) will illuminate the right and left low beam headlamps continuously. The DRLs will operate when the following conditions are met

1. The ignition is in the RUN or CRANK position
2. The shift lever is out of the PARK position for vehicles equipped with automatic transmissions or the parking brake is released for vehicles with manual transmissions
3. The headlamp switch is in the OFF or AUTO position

The ambient light sensor is a light sensitive transistor that varies the voltage signal to the body control module (BCM) based on outside lighting conditions. When the ambient light sensor indicates daytime conditions, the body control module (BCM) grounds the DRL relay control circuit causing voltage to flow from the DRL fuse which energizes the DRL relay. With the DRL relay energized, the switch contacts close and voltage is applied to the left and right low beam headlamps. Any function or condition that turns on the headlamps will cancel DRL operation.

Fog Lamps

When the fog lamp switch is placed in the ON position, ground is applied through the fog lamp switch signal circuit to the body control module (BCM). The BCM applies battery voltage through the fog lamp relay control circuit to the coil side of the fog lamp relay. Battery voltage is applied at all times from the FOG LAMP fuse to the switch side of the fog lamp relay. When the relay coil is energized, the relay switch contacts close and allow battery voltage to be applied from the FOG LAMP fuse, through the relay switch contacts, to the fog lamps.

Park, Tail, License and Marker Lamps

Battery voltage is applied at all times from the PRK LAMPS fuse to both coil and switched sides of the PARK LAMP Relay located in the underhood fuse block. Ground is applied to the turn signal/multifunction switch at all times. When the headlamp switch is place in either the HEAD or PARK position, ground is applied to the park lamp relay control circuit. This energizes the PARK LAMP Relay and applies battery voltage to all park, tail, license, and marker lamps.

Turn Signal Lamps

Ground is applied at all times to the turn signal/multifunction switch. The turn signal lamps may only be activated with the ignition switch in the ON or START position. When the turn signal/multifunction switch is placed in either the TURN RIGHT or TURN LEFT position, ground is applied to the body control module (BCM) through either the right turn or left turn signal switch signal circuit. Battery voltage is applied at all times from the BATT MAIN 3 fuse to the BCM. The BCM then applies a pulsating voltage to the front and rear turn signal lamps.

Hazard Flasher Lamps

The hazard flashers may be activated in any power mode. The hazard switch is permanently grounded. When the hazard switch is placed in the ON position, ground is applied through the hazard switch signal circuit to the body control module (BCM). The BCM supplies battery voltage to all four turn signal lamps in an ON and OFF duty cycle. When the hazard switch is placed in the ON position, the instrument panel cluster (IPC) receives a signal from the hazard switch and applies voltage through the hazard flash indicator circuit to the hazard switch to illuminate the hazard indicator.

Stop Lamps

The brake pedal position sensor is used to sense the action of the driver application of the brake pedal. The brake pedal position sensor provides an analog voltage signal that will increase as the brake pedal is applied. The body control module (BCM) provides a low reference signal and a 5-volt reference voltage to the brake pedal position sensor. When the variable signal reaches a voltage threshold indicating the brakes have been applied, the BCM will apply battery positive voltage to the stop lamps, center high mounted stop lamp (CHMSL), transmission control module (TCM), and engine control module (ECM). The stop lamps on this vehicle will not illuminate unless the ignition is in the accessory, run, or crank positions. When the ignition is in the OFF position the stop lamps will not illuminate when the brake pedal is applied.

Automatic Transmission

The underhood fuse block supplies battery positive voltage to the coil and switch terminals of the BACKUP LAMP relay. When the transmission is placed in the REVERSE position, the engine control module (ECM) sends a serial data message to the body control module (BCM). The message indicates that the gear selector is in the REVERSE position. The BCM grounds the backup lamp relay control circuit of the backup lamps relay. This energizes the backup lamps relay, closing the switch side contacts and provides battery voltage to the BACKUP LAMP fuse through to the backup lamps. The backup lamps are permanently grounded. With both power and ground the backup lamps illuminate. Once the driver moves the gear selector out of the REVERSE position, a message is sent by the ECM via GMLAN serial data requesting the BCM to remove ground from the backup lamp relay control circuit. This opens the backup lamps relay switch contacts turning OFF the backup lamps.

Manual Transmission

Battery voltage is applied to the backup lamp switch when the ignition switch is in the RUN or CRANK positions. When the transmission is placed in the REVERSE position, the backup lamp switch provides battery voltage from the BACKUP LAMP fuse to the backup lamps. The backup lamps are permanently grounded. With both power and ground the backup lamps illuminate. Once the driver moves the gear selector out of the REVERSE position, the backup lamp switch contacts open and the backup lamps turn OFF.

Interior Lamps

The interior lamps consist of 2 groups. The first group are those lamps which may not be dimmed. The 2nd group includes lamps that may be dimmed.

1. Inside rearview mirror lamps
2. Rear Compartment lamp

Courtesy Lamps

The INTERIOR LIGHTS fuse supplies battery voltage to the inadvertent load control relay located in the body control module (BCM). The BCM applies ground to the inadvertent relay control circuit which energizes the inadvertent load control relay coil. With the relay coil energized, the switch contacts close allowing battery voltage to flow from the INTERIOR LIGHTS fuse to the inside rearview mirror lamps through the courtesy lamp supply voltage circuit. The inside rearview mirror lamps are controlled by a 3 position (OFF, DOOR, ON) switch. When the inside rearview mirror switch is placed in the DOOR position, the lamps are controlled by the BCM by grounding the courtesy lamp control circuit. When any door is opened, the jam switch contacts close and the BCM receives a door-open input. If the BCM receives a door lock or unlock input, the BCM will activate the inadvertent relay control circuit, providing battery voltage to the inside rearview mirror lamps. The BCM also provides ground to the inside rearview mirror lamps through the courtesy lamp control circuit.

The courtesy lamps will remain illuminated approximately 10 seconds after the last door closes. Courtesy lamps also turn ON prior to any door being opened, and remain illuminated approximately 30 seconds after the driver removes the ignition key.

The courtesy lamps will normally turn OFF using the theater dimming feature. The BCM provides a pulse width modulated ground to the courtesy lamps for the theater dimming feature. The BCM turns OFF the courtesy lamps if a door lock command is received after all of the doors are closed, or if the ignition switch is turned to either the ON or RUN position.

The BCM will provide interior lamp illumination in the event that an air bag has been deployed. Upon deployment of the air bag the inflatable restraint sensing and diagnostic module (SDM) will send a GMLAN serial data message to the BCM. The BCM will activate the interior lamps approximately 15 seconds after air bag deployment if the Photocell Status is DARK and the ignition is in the ON position. The interior lamps will remain illuminated until there is a change in the power mode.

Keyless Entry Interior Illumination

When the driver uses the remote function actuator (RFA) transmitter to unlock the doors or press the panic button, the BCM will keep the courtesy lamps ON for 30 seconds. If the door locks are activated to the UNLOCK or LOCK position, or if the ignition switch is turned to either the RUN or CRANK position, the courtesy lamps turn OFF immediately. The BCM keeps the courtesy lamps on for 40 seconds after an alarm event is completed.

Rear Compartment Lamp

The INTERIOR LIGHTS fuse supplies battery voltage to the body control module (BCM). The BCM applies battery voltage to the rear compartment lamp through the rear compartment lamp control circuit. The rear compartment lamp is provided ground permanently at G402. When the BCM receives a rear hatch open input, the BCM will activate the rear compartment lamp control circuit to provide battery voltage to the rear compartment lamp.

Interior Lamps Dimming

Interior lamps dimming are lamps that may be dimmed by operating the instrument panel (I/P) dimmer switch. This group consist of the following lamps

1. Fog lamp switch
2. Hazard switch
3. HVAC control head assembly
4. Instrument panel cluster (IPC)
5. Outside rearview mirror switch
6. PRNDL
7. Radio
8. Steering wheel controls
9. Traction Control Switch
10. Window switches

When the park lamps are ON and the ambient light sensor indicates low light conditions, all back lighting will turn ON at the dimming level indicated by the I/P dimmer switch. When the turn signal/multifunction switch is placed in the PARK or HEADLAMP positions, the body control module (BCM) energizes the park lamp relay coil control circuit and dims the interior lamps to the dimming level indicated by the I/P dimmer switch. When the driver selects a dimming setting by moving the I/P dimming switch potentiometer, all back lighting lamps are provided with a specific voltage. When the I/P dimmer switch is moved from MIN to MAX, all back lighting components respond from minimum intensity to maximum brightness in response to the I/P dimmer switch.

The driver may select parade mode by manually turning on the park lamps during daylight conditions.

Battery Rundown Protection/Inadvertent Power

To provide battery run down protection, the interior lamps will be deactivated automatically under certain conditions. The body control module (BCM) initiates a 20 minute timer if the interior lamp relay control output is still active, and the ignition switch is in the OFF position. At the end of the designated time, the BCM will deactivate the interior lamp relay, disabling the interior lamps. This feature will be cancelled if any power mode other than OFF becomes active. The BCM will reset the timer if any interior lamp switch is turned ON, a door is opened, or the remote control door lock receiver (RCDLR) module is activated.

Special Tools

Illustration Tool Number/Description J 25070 Heat Gun - 500-700°F

See also:
• Diagnostic System Check - Vehicle
• Strategy Based Diagnosis
• Diagnostic Procedure Instructions
• Component Connector End Views
• Circuit Testing
• Connector Repairs
• Testing for Intermittent Conditions and Poor Connections
• Wiring Repairs
• Control Module References
• Diagnostic Repair Verification
• Relay Replacement (Attached to Wire Harness)
• Inside Rearview Mirror Replacement
• Electronic Traction Control Switch Replacement
• Front Side Door Window Switch Replacement
• Radio Replacement (SKY)
• Instrument Cluster Replacement (Solstice)
• Heater and Air Conditioning Control Replacement
• Transmission Control Lever Knob Replacement (SKY)
• Checking Aftermarket Accessories
• Backup Lamp Switch Replacement
• Release Systems Schematics
• Symptoms - Hydraulic Brakes
• Turn Signal Multifunction Switch Replacement
• Fastener Caution
• Fastener Tightening Specifications
• Instrument Cluster Trim Panel Replacement (Solstice)
• Halogen Bulb Warning
• Hood Adjustment
• Lifting and Jacking the Vehicle
• Front Wheelhouse Liner Replacement (Base)
• Rear Bumper Fascia Replacement (SKY)
• DTC B2530
• Parking and Turn Signal Lamp Replacement (SKY)
• Brake Pedal Position Sensor Calibration
• Brake Pedal Position Sensor Replacement
• Front Fog Lamps Malfunction
• Interior Backlighting Malfunction
• Stop Lamps Malfunction
• Parking and Turn Signal Lamp Bulb Replacement (SKY)
• Headlamp Aiming (SKY)
• Fastener Tightening Specifications
• Special Tools
