BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| A/C CLTCH Relay | Underhood fuse block. (Scheme 21) |
| Blower Motor High-Speed Relay (11) | Blower motor. (Scheme 31) |
| COOL FAN 1 Relay | Underhood fuse block. (Scheme 21) |
| COOL FAN 2 Relay | Underhood fuse block. (Scheme 21) |
| CRNK Relay | Underhood fuse block. (Scheme 21) |
| Driver Door Unlock (PCB) Relay | Integral to body control module block. |
| FOG LAMP Relay | Underhood fuse block. (Scheme 21) |
| FUEL PUMP Relay | Underhood fuse block. (Scheme 21) |
| HI BEAM Relay | Underhood fuse block. (Scheme 21) |
| HORN Relay | Underhood fuse block. (Scheme 21) |
| HVAC Relay | Body control module. (Scheme 25) |
| Inadvertent Load Control (PCB) Relay | Integral to body control module block. |
| LO BEAM Relay | Underhood fuse block. (Scheme 21) |
| PRK LAMPS Relay | Underhood fuse block. (Scheme 21) |
| RAP Relay | Body control module. (Scheme 25) |
| REAR DEFOG Relay | Underhood fuse block. (Scheme 21) |
| RUN/CRANK Relay | Underhood fuse block. (Scheme 21) |
| TRUNK RELSE Relay | Underhood fuse block. (Scheme 21) |
| WPR Relay | Underhood fuse block. (Scheme 21) |
| WPR Relay | Underhood fuse block. (Scheme 21) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| Fuse Block - Underhood | Right rear corner of engine compartment. (Scheme 59) |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| Body Control Module | Right of HVAC module. (Scheme 51) |
| Electronic Brake Control Module (EBCM) | Left side of engine compartment. (Scheme 1) |
| Engine Control Module (ECM) (4) | Left rear corner of engine compartment. (Scheme 26) |
| HVAC Control Module (6) | Center of dash. (Scheme 31) |
| Inflatable Restraint I/P Module | Under right side of dash. (Scheme 3) |
| Inflatable Restraint Passenger Presence System (PPS) Module | Under front passenger's seat. (Scheme 15) |
| Inflatable Restraint Sensing & Diagnostic Module (SDM) | Under front passenger's seat. (Scheme 14) |
| Inflatable Restraint Steering Wheel Module (1) | In steering wheel. (Scheme 34) |
| Remote Control Door Lock Receiver (RCDLR) | Center OF driver's seat back. (Scheme 5) |
| Theft Deterrent Module (1) | Top right of steering column. (Scheme 64) |
| Transmission Control Module (TCM) (5) | Near brake master cylinder. (Scheme 26) |
| Vehicle Communication Interface Module (VCIM) | Rear of center console. (Scheme 5) |
CONTROL UNITS LOCATION
MOTORS
| Component | Location |
|---|---|
| Air Temperature Actuator - Left (2) | Left of HVAC module. (Scheme 31) |
| Air Temperature Actuator - Right (1) | Right of HVAC module. (Scheme 31) |
| Blower Motor (9) | Right side of dash. (Scheme 31) |
| Brake Booster Pump Motor | Left of engine. (Scheme 23) |
| Door Latch - Driver | Driver's door. (Scheme 52) |
| Door Latch - Passenger | Front passenger's door. (Scheme 53) |
| Engine Cooling Fan | Behind radiator. (Scheme 10) |
| Folding Top Cover Actuator | Base of rear window. (Scheme 4) |
| Fuel Pump & Sender Assembly | Inside fuel tank. (Scheme 9) |
| High Pressure Fuel Pump | Top left rear of engine. (Scheme 24) |
| Mode Actuator (3) | Left of HVAC module. (Scheme 31) |
| Rear Compartment Lid Release Actuator | Base of convertible top. (Scheme 6) |
| Recirculation Actuator (2) | Right side of dash. (Scheme 35) |
| Seat Front Vertical Motor - Driver (5) | Under front of driver's seat. (Scheme 38) |
| Starter Motor (2.0L) | Lower left rear of engine. (Scheme 55) |
| Starter Motor (2.4L) | Lower left rear of engine. (Scheme 54) |
| Throttle Body (2.0L) | Left side of engine. (Scheme 55) |
| Throttle Body (2.4) | Left side of engine. (Scheme 54) |
| Window Motor - Driver | Driver's door. (Scheme 52) |
| Window Motor - Passenger | Front passenger's door. (Scheme 53) |
| Windshield Washer Fluid Pump | Bottom of washer fluid reservoir. (Scheme 8) |
| Windshield Wiper Motor & Module | Left side of firewall. (Scheme 8) |
MOTORS LOCATION
SENDING UNITS & SENSORS
| Component | Location |
|---|---|
| Accelerator Pedal Position (APP) Sensor | Top of accelerator pedal bracket. (Scheme 30) |
| A/C Refrigerant Pressure Sensor (2) | Top left of engine. (Scheme 44) |
| Ambient Light Sensor (4) | Top of dash. (Scheme 31) |
| Automatic Transmission Input Shaft Speed Sensor (ISS) | In transmission. |
| Automatic Transmission Output Shaft Speed Sensor (OSS) | In transmission. |
| Brake Booster Vacuum Sensor | Brake vacuum booster. (Scheme 23) |
| Brake Pedal Position Sensor | Top of brake pedal lever. (Scheme 30) |
| Camshaft Position (CMP) Sensor - Exhaust (2.0L) | Top right rear of engine. |
| Camshaft Position (CMP) Sensor - Exhaust (2.4L) | Top right rear of engine. (Scheme 56) |
| Camshaft Position (CMP) Sensor - Intake (2.0L) | Top left rear of engine. |
| Camshaft Position (CMP) Sensor - Intake (2.4L) | Top left rear of engine. (Scheme 56) |
| Clutch Pedal Position (CPP) Sensor | Top of clutch pedal bracket. |
| Clutch Pedal Position Sensor | Top of clutch pedal lever. (Scheme 30) |
| Crankshaft Position (CKP) Sensor (2.0L) | Left rear of engine. (Scheme 24) |
| Crankshaft Position (CKP) Sensor (2.4L) | Lower left corner of engine. (Scheme 54) |
| Engine Coolant Temperature (ECT) Sensor (7) | Left rear corner of engine block. (Scheme 27) |
| Engine Oil Pressure (EOP) Sensor (2.0L) | Lower left rear of engine. (Scheme 24) |
| Engine Oil Pressure (EOP) Sensor (2.4L) | Lower left rear of engine. (Scheme 54) |
| Evaporator Temperature Sensor (1) | Right side of dash. (Scheme 35) |
| Fuel Rail Pressure (FRP) Sensor | Left front of engine. (Scheme 23) |
| Fuel Tank Pressure (FTP) Sensor (4) | Integral to fuel pump & sender assembly. (Scheme 49) |
| Heated Oxygen Sensor (HO2S) 1 (2.0L) | Upstream of catalytic converter. (Scheme 57) |
| Heated Oxygen Sensor (HO2S) 1 (2.4L) | Upstream of catalytic converter. (Scheme 56) |
| Heated Oxygen Sensor (HO2S) 2 (2.0L) | Downstream of catalytic converter. (Scheme 57) |
| Heated Oxygen Sensor (HO2S) 2 (2.4L) | Downstream of catalytic converter. (Scheme 56) |
| Inflatable Restraint Front End Discriminating Sensor - Left | Front of left frame rail. (Scheme 1) |
| Inflatable Restraint Front End Discriminating Sensor - Right | Front of right frame rail. (Scheme 1) |
| Intake Air Pressure & Temperature Sensor | Left front of engine. (Scheme 23) |
| Knock Sensor (KS) 1 | Lower left front of engine. (Scheme 24) |
| Knock Sensor (KS) 2 (2.0L) | Lower left side of engine. (Scheme 24) |
| Knock Sensor (KS) (2.4L) | Lower left side on engine. (Scheme 54) |
| Manifold Absolute Pressure (MAP) Sensor (2.0L) | Left side of engine. (Scheme 24) |
| Manifold Absolute Pressure (MAP) Sensor (2.4L) | Left side of engine. (Scheme 54) |
| Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (2) | In air intake duct. (Scheme 42) |
| Outside Air Temperature Sensor (1) | Behind left front headlight. (Scheme 41) |
| Steering Angle Sensor | Base of steering column. (Scheme 30) |
| Transmission Fluid Temperature (TFT) Sensor | Transmission assembly. |
| Vehicle Speed Sensor (VSS) | Manual transmission. (Scheme 7) |
| Wheel Speed Sensor (WSS) - LF | Left front wheel hub assembly. (Scheme 2) |
| Wheel Speed Sensor (WSS) - LR | Left rear wheel hub assembly. (Scheme 2) |
| Wheel Speed Sensor (WSS) - RF | Right front wheel hub assembly. (Scheme 2) |
| Wheel Speed Sensor (WSS) - RR | Right rear wheel hub assembly. (Scheme 2) |
| Yaw & Lateral Acceleration Sensor (2) | Under front passenger's seat. (Scheme 39) |
SENDING UNITS & SENSORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| A/C Compressor Clutch | Left front corner of engine. (Scheme 11) |
| Automatic Transmission Shift Lock Control Solenoid | Base of shifter. (Scheme 16) |
| Camshaft Position (CMP) Actuator Solenoid Valve - Exhaust (2.0L) | Top front of engine. (Scheme 24) |
| Camshaft Position (CMP) Actuator Solenoid Valve - Exhaust (2.4L) | Left of ignition coil 1. (Scheme 56) |
| Camshaft Position (CMP) Actuator Solenoid Valve - Intake (2.0L) | Top front of engine. (Scheme 24) |
| Camshaft Position (CMP) Actuator Solenoid Valve - Intake (2.4L) | Left of ignition coil 1. (Scheme 56) |
| Charge Air Bypass Valve Solenoid | Left of engine, between intake runner port. |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve (2.0L) | Left side of engine. (Scheme 24) |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve (2.4L) | Top left rear corner of engine. (Scheme 56) |
| Evaporative Emission (EVAP) Canister Vent Solenoid Valve (6) | Rear of fuel tank. (Scheme 49) |
| Fuel Injectors 1, 2, 3 & 4 (2.0L) | Top of respective cylinder. (Scheme 24) |
| Fuel Injectors 1, 2, 3 & 4 (2.4L) | Top of respective cylinder. |
| Ignition Lock Cylinder Control Actuator | Ignition switch. (Scheme 17) |
| Pressure Control (PC) Solenoid Valve | On transmission. |
| Rear Compartment Lid Latch Release Actuator (Convertible) | Below rear window. (Scheme 65) |
| Rear Compartment Lid Latch/Window Release Actuator (Coupe) | Center rear of rear compartment. |
| Torque Converter Clutch (TCC) Pulse Width Modulation (PWW) Solenoid Valve | Transmission assembly. |
| Turbocharger Wastegate Solenoid | Under turbocharger. (Scheme 57) |
| 1-2 Shift Solenoid (SS) Valve | Transmission assembly. |
| 2-3 Shift Solenoid (SS) Valve | Transmission assembly. |
| 4-5 Shift Solenoid (SS) Valve | Transmission assembly. |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| Automatic Transmission Manual Shift Shaft Switch | Transmission assembly. |
| Backup Lamp Switch | Right side of transmission. (Scheme 7) |
| Brake Fluid Level Switch | Brake fluid reservoir. (Scheme 23) |
| Engine Coolant Level Switch | Left rear corner of engine compartment. (Scheme 8) |
| Engine Oil Pressure (EOP) Switch | Left rear of engine. (Scheme 24) |
| Horn Switch | In steering wheel. (Scheme 22) |
| Park Brake Switch | Left of park brake lever. (Scheme 63) |
| Park Position Switch | In transmission shift control assembly. |
| Rear Compartment Lid Ajar Switch | Below rear window. (Scheme 4) |
| Seat Belt Switch - Driver (3) | In seat belt buckle. (Scheme 38) |
| Seat Belt Switch - Passenger | In seat belt buckle. (Scheme 15) |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| Audio Amplifier | Behind left seat. (Scheme 22) |
| Blower Motor Resistor (12) | Below blower motor. (Scheme 31) |
| Cellular & Navigation Antenna | Rear compartment lid. (Scheme 5) |
| Cellular Telephone Microphone | Top left side of dash. (Scheme 5) |
| Data Link Connector (DLC) | Left side of dash. |
| Data Link Resistor | Left side of dash. (Scheme 30) |
| Digital Radio Receiver | Behind right rear wheel hub assembly. (Scheme 13) |
| Engine Block Heater Connector | Right side of engine. (Scheme 56) |
| Generator (2.0L) | Left front of engine. (Scheme 55) |
| Generator (2.4L) | Left front of engine. (Scheme 54) |
| Horn | Left front corner of engine compartment. (Scheme 12) |
| Ignition Coils 1, 2, 3 & 4 (2.0L) | Top of respective cylinder. (Scheme 24) |
| Ignition Coils 1, 2, 3 & 4 (2.4L) | Top of respective cylinder. (Scheme 58) |
| Seat Belt Retractor Pretension - Driver | Integral to driver's seat belt retractor. (Scheme 14) |
| Seat Belt Retractor Pretensioner - Passenger | Integral to front passenger's seat belt retractor. (Scheme 14) |
MISCELLANEOUS LOCATION
CONNECTORS
| Component | Location |
|---|---|
| X100 (Black, 40 Pin) | Below underhood fuse block. (Scheme 27) |
| X102 (Gray, 4 Pin) (5) | Right front of engine compartment. (Scheme 43) |
| X103 (Gray, 4 Pin) (12) | Left front of engine compartment. (Scheme 43) |
| X110 (Black, 4 Pin) | Forward lamp harness to left headlight assembly. |
| X111 (Black, 4 Pin) (1) | Behind left front fender. (Scheme 43) |
| X120 (Black, 16 Pin) (10) | Right rear of engine compartment. (Scheme 43) |
| X122 (Black, 2 Pin) (5) | Left side firewall. (Scheme 66) |
| X160 (Black, 8 Pin) (1) | Top rear of engine. (Scheme 27) |
| X162 (12 Pin) (2) | Left front of engine. (Scheme 28) |
| X175 (Black, 20 Pin) | Right Rear of Transmission. (Scheme 33) |
| X200 (12 Pin) | Right front foot well, next to BCM. |
| X207 (12 Pin) (1) | Near front of floor console. (Scheme 37) |
| X208 (Yellow, 4 Pin) (13) | Behind right side of dash. (Scheme 31) |
| X216 (8 Pin) (7) | Behind right side of dash. (Scheme 31) |
| X218 (12 Pin) (8) | Behind right side of dash. (Scheme 31) |
| X316 (Black, 8 Pin) (10) | Right front seat. (Scheme 40) |
| X317 (W/O Power Seat) (Black, 3 Pin) (1) | Driver's seat. (Scheme 38) |
| X317 (W/Power Seat) (Black, 4 Pin) (1) | Driver's seat. (Scheme 38) |
| X400 (Black, 4 Pin) (1) | Front of right rear tail light. (Scheme 46) |
| X401 (Black, 8 Pin) (12) | Behind right rear wheelwell. (Scheme 36) |
| X405 (Gray, 6 Pin) (1) | Behind right rear taillight. (Scheme 47) |
| X406 (Blue, 8 Pin) (5) | Behind right rear quarterpanel. (Scheme 46) |
| X407 (Gray, 6 Pin) (15) | Right tail lamp assembly. (Scheme 49) |
| X408 (Blue, 8 Pin) (6) | Behind right rear quarterpanel. (Scheme 46) |
| X410 (Black, 6 Pin) | Center rear of compartment. (Scheme 47) |
| X416 (Black, 2 Pin) | Behind front passenger's seat back. |
| X417 (Black, 3 Pin) | Near lift glass actuator. |
| X500 (Black, 10 Pin) | Base of left "A" pillar. (Scheme 30) |
| X501 (Black, 8 Pin) | Base of left "A" pillar. (Scheme 30) |
| X600 (Black, 16 Pin) (3) | Base of right "A" pillar. (Scheme 32) |
CONNECTORS LOCATION
GROUNDS
| Component | Location |
|---|---|
| G101 | Left front corner of engine compartment. (Scheme 18) |
| G102 | Right front corner of engine compartment. (Scheme 18) |
| G103 | Lower right rear corner of engine. |
| G104 (2.0L) | Right rear corner of engine. (Scheme 62) |
| G104 (2.4L) | Right front corner of engine. (Scheme 61) |
| G105 | On front of left frame rail. (Scheme 18) |
| G106 | Mounted on outside of frame rail. (Scheme 19) |
| G300 | Center console. (Scheme 20) |
| G301 | Left "B" pillar. |
| G302 | Right "B" pillar. |
| G303 | On rear support behind driver seat. (Scheme 20) |
| G304 | On rear support behind driver seat. (Scheme 20) |
| G400 | On rear of right frame rail. (Scheme 60) |
| G402 | On rear of right frame rail. (Scheme 60) |
GROUNDS LOCATION
SPLICES
| Component | Location |
|---|---|
| J100 | Forward lamp harness, 40.5 cm from horn breakout. |
| J101 (17) | Forward lamp harness, 10 cm from electronic brake control module breakout. (Scheme 43) |
| J102 | Forward lamp harness, 15 cm from brake fluid level switch breakout. |
| J103 (11) | Forward lamp harness, 10 cm from outside air temperature sensor breakout. (Scheme 43) |
| J104 (2) | Engine harness, 12 cm from generator breakout. (Scheme 26) |
| J105 (7) | Forward lamp harness. (Scheme 43) |
| J106 (2) | Engine harness. (Scheme 27) |
| J107 (1) | Engine harness, 3 cm from HO2S 1 breakout. (Scheme 27) |
| J108 (3) | Engine harness, 5 cm from brake fluid level switch breakout. (Scheme 26) |
| J109 (15) | Forward lamp harness. (Scheme 43) |
| J110 | Engine harness, 10 cm from brake fluid level switch breakout. |
| J115 (3) | Forward lamp harness, 8 cm from G102 breakout. (Scheme 43) |
| J116 | Engine harness, 13.5 cm from X100 breakout. |
| J117 | Engine harness, 11.5 cm from ignition coil 1 breakout. |
| J118 | Internal splice, inside transmission. |
| J119 | Fuel injector harness. |
| J120 (8) | Engine harness, 49 cm from brake fluid level switch breakout. (Scheme 49) |
| J121 | Engine harness, 4.5 cm from G104 breakout. (Scheme 29) |
| J123 | Engine harness, 3 cm from ignition coil 3 breakout. (Scheme 29) |
| J124 | Engine harness, 3 cm from ignition coil 3 breakout. (Scheme 29) |
| J126 | Engine harness, 4.5 cm from G104 breakout. |
| J128 | Forward lamp harness, 25.5 cm from underhood fuse block. |
| J129 (8) | Forward lamp harness, 28 cm from underhood fuse block. (Scheme 43) |
| J130 (13) | Forward lamp harness, 21 cm from left front wheel speed sensor breakout. (Scheme 43) |
| J131 (14) | Forward lamp harness, 15 cm from electronic brake control module. (Scheme 43) |
| J134 (6) | I/P body harness, 29.5 cm from the underhood fuse block breakout. (Scheme 45) |
| J136 (7) | I/P body harness, 67.5 cm from underhood fuse block breakout. (Scheme 45) |
| J137 (5) | Engine harness, 4 cm from engine coolant level switch breakout. (Scheme 28) |
| J140 | Engine harness, 5 cm from ignition coil 4 breakout. (Scheme 29) |
| J141 (7) | Engine harness, 15 cm from windshield washer fluid pump. (Scheme 28) |
| J142 (6) | Engine harness, 7 cm from MAP sensor breakout. (Scheme 28) |
| J200 | I/P body harness, 33 cm from rear defogger grid breakout. |
| J201 | I/P body harness, 40 cm from underhood fuse block. |
| J202 | I/P body harness, 68 cm from underhood fuse block breakout. |
| J203 | I/P body harness, 10 cm from HVAC module breakout. |
| J204 | I/P body harness, 6 cm from body control module breakout. |
| J205 | I/P body harness. |
| J206 | I/P body harness, 13.5 cm from body control module. |
| J207 | I/P body harness. |
| J208 | I/P body harness, 8 cm from the IPC breakout. |
| J209 | I/P body harness, 4 cm from hazard switch breakout. |
| J211 | I/P body harness. |
| J212 | I/P body harness. |
| J213 | I/P body harness. |
| J214 | I/P body harness, 74 cm from G301 breakout. |
| J216 | I/P body harness, 7 cm from accelerator pedal position sensor breakout. |
| J217 | I/P body harness, 16 cm from telephone microphone. |
| J218 | I/P body harness, 7 cm from VCIM breakout. |
| J221 | I/P body harness. |
| J222 | I/P body harness. |
| J225 | HVAC harness. |
| J231 | HVAC Harness. |
| J232 | HVAC Harness. |
| J233 | HVAC Harness. |
| J234 | HVAC Harness. |
| J300 (1) | I/P body harness, 31 cm from G300 breakout. (Scheme 40) |
| J301 | I/P body harness, 30 cm from G300 ground breakout. |
| J302 (6) | Driver seat harness, 5 cm from seat vertical motor breakout. (Scheme 38) |
| J303 (11) | I/P body harness, 10 cm from yaw & lateral acceleration sensor breakout. (Scheme 40) |
| J304 | I/P body harness, 18 cm from yaw & lateral acceleration sensor breakout. |
| J309 | I/P body harness, 17 cm from X401 connector breakout. |
| J310 (10) | I/P body harness, 4.5 cm from auxiliary power outlet. (Scheme 40) |
| J311 (4) | I/P body harness. (Scheme 40) |
| J315 | I/P body harness, 11 cm from VCIM breakout. |
| J318 (7) | I/P body harness, 8 cm from G300 breakout. (Scheme 40) |
| J400 | I/P body harness. |
| J401 (2) | Rear chassis harness, 7.5 cm from X406 breakout. (Scheme 46) |
| J402 (4) | Rear chassis harness. (Scheme 46) |
| J403 (2) | I/P body harness, 16.5 cm from X400. (Scheme 46) |
| J405 | Rear chassis harness, 82 cm from left rear wheel speed sensor. |
| J406 | Left Tail lamp harness, 5 cm from X405 connector. |
| J407 | Right tail lamp harness, 5 cm from X406 connector. |
| J408 | Left tail lamp harness, 5 cm from X405 connector. |
| J409 | Right tail lamp harness, 5 cm from X406 connector. |
| J410 (10) | Left tail light assembly. (Scheme 49) |
| J412 | XM jumper harness, 28.5 cm from digital radio. |
| J413 | XM jumper harness, 10 cm from digital radio. |
| J415 | I/P body harness, 33 cm from rear compartment lamp. |
| J416 | Rear tail lamp harness, 18 cm from X400 connector. |
| J420 | Tail lamp harness, 19 cm from right tail lamp breakout. |
| J500 (8) | Left front door harness. (Scheme 50) |
| J501 (6) | Left door harness, 32 cm from outside rearview mirror switch. (Scheme 50) |
| J600 (5) | Right door harness, 8 cm from door grommet. (Scheme 48) |
| J601 | Right door harness, 15.5 cm from door grommet. |
SPLICES LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
