Wiper System & Washer System: Specifications — Wiper System & Washer System — Wiper/washer Systems

Wiper System & Washer System: Specifications Pontiac Solstice I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Washer Solvent Container Nuts	10 N.m	89 lb in
Wiper Arm Nut	35 N.m	25 lb ft
Wiper Module Bolts	10 N.m	89 lb in
Wiper Motor Bolts	4.5 N.m	40 lb in
Wiper Motor Support Bracket Screws	5.5 N.m	49 lb in

Fastener Tightening Specifications

Scheme 1: Wiper/Washer Schematics

Scheme 2: Wiper/Washer Component Views

Callout	Component Name
1	Windshield Wiper Motor and Module
2	Coolant Surge Tank
3	Engine Control Module (ECM) Connectors
4	Engine Control Module (ECM)
5	Transmission Control Module (TCM) (M82)
6	Transmission Control Module (TCM) Connector (M82)
7	Windshield Washer Fluid Pump
8	Windshield Washer Fluid Container
9	Engine Coolant Level Switch
10	Coolant Surge Tank
11	Brake Fluid Level Switch
12	Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor

Callouts For (Scheme 2)

Callout	Component Name
1	Inflatable Restraint Steering Wheel Module
2	Turn Signal/Multifunction Switch C2
3	Turn Signal/Multifunction Switch C1
4	Inflatable Restraint Steering Wheel Module Coil C3
5	Inflatable Restraint Steering Wheel Module Coil C2
6	Ignition Switch
7	Windshield Wiper/Washer Switch Connector
8	Windshield Wiper/Washer Switch

Callouts For (Scheme 3)

Scheme 4: Windshield Washer Fluid Pump

Connector Part Information OEM: 12052641 Service: 12102747 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Windshield Washer Fluid Pump Connector Part Information

Pin	Wire Color	Circuit No.	Function
A	OG	228	Windshield Washer Pump Control
B	BK	250	Ground

Windshield Washer Fluid Pump Connector Terminal Identification

Scheme 5: Windshield Wiper Motor Assembly

Connector Part Information OEM: 15393432 Service: 89046627 Description: 5-Way F 090 II Class iii Series, Sealed (BK)
Terminal Part Information Pins: 1, 4, 5 Terminal/Tray: 7116-4026/11 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 15313892/J-35616-18 (BK) Pins: 2 Terminal/Tray: 7116-4025/11 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15313892/J-35616-18 (BK)

Windshield Wiper Motor Assembly Connector Part Information

Pin	Wire Color	Circuit No.	Function
1	BK	250	Ground
2	YE	196	Windshield Wiper Motor Park Switch Signal
3			Not Used
4	PU	92	Windshield Wiper Motor High Speed Control
5	D-GN	95	Windshield Washer Switch Signal

Windshield Wiper Motor Assembly Connector Terminal Identification

Scheme 6: Windshield Wiper/Washer Switch

Connector Part Information OEM: 12059800 Service: 15306169 Description: 5-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Pins: B, C, D, E Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Windshield Wiper/Washer Switch Connector Part Information

Pin	Wire Color	Circuit No.	Function
A			Not Used
B	OG	228	Windshield Washer Pump Control
C	L-GN	1715	Windshield Wiper Switch High Signal
D	PK	439	Ignition 1 Voltage
E	GY	112	Windshield Wiper Switch Signal

Windshield Wiper/Washer Switch Connector Terminal Identification
