Engine Controls & Fuel - 2.0L - Introduction (2 of 2): Specifications Pontiac Solstice I

Testing & Diagnostics 1 illustration

Ignition System Specifications

Application	Specification
Application	Metric	English
Ignition Type	Coil-On-Plug
Firing Order	1-3-4-2
Spark Plug Type	GM P/N 12590701
Spark Plug Torque	17-23 N.m	12.5-17 lb ft
Spark Plug Gap	0.9 mm	0.035 in

Ignition System Specifications

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Accelerator Pedal Position (APP) Sensor Nut	10 N.m	89 lb in
Air Cleaner Front Bolt/Nut	10 N.m	89 lb in
Air Cleaner Outlet Duct Clamp	4 N.m	35 lb in
Brake Pipe	20 N.m	15 lb ft
Camshaft Position Actuator Solenoid Valve Bolt	10 N.m	89 lb in
Camshaft Position (CMP) Sensor Bolt	10 N.m	89 lb in
Charge Air Cooler Bolt	9 N.m	80 lb in
Charge Air Cooler Hose Clamp	5 N.m	44 lb in
Charge Air Cooler Pipe Clamp	5 N.m	44 lb in
Charge Air Cooler Pipe Bolt	9 N.m	80 lb in
Charge Air Cooler Rear Bracket Nut	9 N.m	80 lb in
Charge Air Bypass Solenoid Bolt	10 N.m	89 lb in
Crankshaft Position (CKP) Sensor Bolt	10 N.m	89 lb in
Engine Coolant Temperature (ECT) Sensor	20 N.m	15 lb ft
Evaporative Emission (EVAP) Canister Purge Solenoid Bolt	10 N.m	89 lb in
Fuel Feed Pipe Bolt	10 N.m	89 lb in
Fuel Feed Pipe Fitting	30 N.m	22 lb ft
Fuel Fill Hose Clamp	2.5 N.m	22 lb in
Fuel Fill Pipe Ground Strap Bolt	9 N.m	80 lb in
Fuel Fill Pipe to Housing Bolt	1.5 N.m	13 lb in
Fuel Injector Fuel Rail Fuel Pressure Sensor	33 N.m	25 lb ft
Fuel Pump Module Access Cover Bolt	10 N.m	89 lb in
Fuel Rail Bolt	22 N.m	16 lb ft
Fuel Tank Strap/Support Bolt	22 N.m	16 lb ft
Heated Oxygen Sensor (HO2S)	42 N.m	31 lb ft
High Pressure Fuel Feed Pipe Fitting	30 N.m	22 lb ft
High Pressure Fuel Pump Cover Bolt	10 N.m	89 lb in
High Pressure Fuel Pump Bolt	15 N.m	11 lb ft
Ignition Coil Bolt	10 N.m	89 lb in
Intake Air Pressure and Temperature Sensor Bolt	9 N.m	80 lb in
Knock Sensor	25 N.m	18 lb ft
Manifold Absolute Pressure (MAP) Sensor Bolt	10 N.m	89 lb in
Mass Air Flow (MAF) Sensor Screw	0.6 N.m	5 lb in
Spark Plug	20 N.m	15 lb ft
Throttle Body Bolt	10 N.m	89 lb in

Fastener Tightening Specifications

Scheme 68

Scheme 68: Evaporative Emissions Hose Routing Diagram

Scheme 68: Evaporative Emissions Hose Routing Diagram

Callout	Component Name
1	Fuel Tank Pressure (FTP) Sensor
2	Fuel Tank
3	Evaporative Emission (EVAP) Vent Solenoid Valve
4	EVAP Canister
5	Purge Flow Check Valve
6	EVAP Purge Solenoid Valve
7	Fill Limit Vent Valve (FLVV)
8	Grade Vent Valve

Callouts For (Scheme 68)
