Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Ignition Lock Cylinder Solenoid Screw | 2 N.m | 17 lb in |
| Ignition Switch Screws | 2 N.m | 17 lb in |
| Intermediate Shaft Pinch Bolt | 58 N.m | 43 lb ft |
| Multi-Function Turn Signal/Headlamp Switch Screw | 2 N.m | 17 lb in |
| Steering Column Mid Pivot Bolt | 25 N.m | 18 lb ft |
| Steering Column Mounting Bolt | 25 N.m | 18 lb ft |
| Steering Column Trim Cover Screws | 2.6 N.m | 23 lb in |
| Steering Column Upper Jacket Bolt | 11 N.m | 97 lb in |
| Steering Wheel Control Switch | 2 N.m | 18 lb in |
| Steering Wheel Nut | 37 N.m | 27 lb ft |
Fastener Tightening Specifications
Scheme 1
| Callout | Component Name |
|---|---|
| 1 | Intermediate Steering Shaft |
| 2 | Intermediate Steering Shaft Nut |
| 3 | Intermediate Steering Shaft Bolt |
| 4 | Ignition Switch Screws |
| 5 | Ignition Switch |
| 6 | Steering Column Upper Trim Cover |
| 7 | Ignition Lock Cylinder Case Shear Bolt |
| 8 | Ignition Lock Cylinder Case Clamp |
| 9 | Ignition Lock Cylinder Case |
| 10 | Steering Wheel |
| 11 | Steering Wheel Control Switches |
| 12 | Steering Wheel Control Switch Screws |
| 13 | Windshield Wiper/Washer Switch |
| 14 | Multi-Function Switch Housing |
| 15 | Steering Wheel Inflatable Restraint Module |
| 16 | Steering Wheel Nut |
| 17 | SIR Coil Screws |
| 18 | SIR Coil |
| 19 | Steering Column Lower Trim Cover |
| 20 | Steering Column Lower Trim Cover Screws |
| 21 | Steering Column Lower Trim Cover Plug |
| 22 | Steering Column Upper Mounting Bolt |
| 23 | Steering Column |
| 24 | Turn Signal Switch |
| 25 | Steering Column Lower Mounting Bolt |
Callouts For (Scheme 1)
Symptoms - Steering Wheel and Column
Review the system description and operation in order to familiarize yourself with the system functions. Refer to Power Steering System Description and Operation .
