Horn System: Overview Pontiac Solstice I

Horn Schematic Icons

Horn Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to Sir Disabling And Enabling . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 2

Callouts For (Scheme 2)

Scheme 3

Horn Connector Part Information

Horn Connector Terminal Identification

Scheme 4

Horn Switch Connector Part Information

Horn Switch Connector Terminal Identification

Circuit/System Description

Battery positive voltage is applied at all times to the horn relay coil and horn relay switch. Pressing the horn switch applies ground to the horn relay control circuit. The body control module (BCM) also may apply ground to the horn relay control circuit. When the horn relay control circuit is grounded, the horn relay is energized and battery positive voltage is applied to the horn via the horn control circuit. The horn will sound as long as ground is applied to the horn relay control circuit.

Battery positive voltage is applied at all times to the horn relay coil and horn relay switch. Pressing the horn switch applies ground to the horn relay control circuit. The body control module (BCM) also may apply ground to the horn relay control circuit. When the horn relay control circuit is grounded, the horn relay is energized and battery positive voltage is applied to the horn via the horn control circuit. The horn will sound as long as ground is applied to the horn relay control circuit.

Battery positive voltage is applied at all times to the horn relay coil and horn relay switch. Pressing the horn switch applies ground to the horn relay control circuit. The body control module (BCM) also may apply ground to the horn relay control circuit. When the horn relay control circuit is grounded, the horn relay is energized and battery positive voltage is applied to the horn via the horn control circuit. The horn will sound as long as ground is applied to the horn relay control circuit.

Battery positive voltage is applied at all times to the horn relay coil and horn relay switch. Pressing the horn switch applies ground to the horn relay control circuit. The body control module (BCM) also may apply ground to the horn relay control circuit. When the horn relay control circuit is grounded, the horn relay is energized and battery positive voltage is applied to the horn via the horn control circuit. The horn will sound as long as ground is applied to the horn relay control circuit.

System Description

The horn system consists of the following components

1. Horn relay
2. Horn switch
3. Horn assembly
4. Body control module (BCM)
5. Steering wheel coil assembly

System Operation

Both the horn switch and body control module (BCM) may command the horns on.

The BCM controls the horn under any of the following conditions

1. When the content theft deterrent (CTD) systems determines an alarm condition exists, the horn may sound as part of the alarm cycle.
2. When the panic button is depressed on the remote control door lock transmitter. For further information refer to «Keyless Entry System Description and Operation»(ref-267929-S42136774102007101700000) .
3. When the keyless entry system is used to lock the vehicle, a horn chirp may sound to notify the driver that the vehicle has been locked.

The horn switch controls the horn only when the horn switch is depressed.

Circuit Operation

Battery positive voltage is applied at all times to the horn relay coil and the horn relay switch. Pressing the horn switch applies ground to the horn switch signal circuit. The body control module (BCM) also may apply ground to the horn relay control circuit as described above. When the horn relay control circuit is grounded, the horn relay is energized and battery positive voltage is applied to the horns through the horn control circuit. The horns sound as long as ground is applied to the horn relay control circuit.
