Wiring diagram: Headlights — Headlights circuit Pontiac GTO IV
All systems — 27 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 6.0l vin u
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power mirrors
- Power seats 2
- Power windows
- Radio
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Headlights
# Headlights circuit
# Headlights circuit (1 of 2)
Components on the diagram
# Headlights circuit (2 of 2)
